SIMATIC IPC477E 15″ ST (1280 x 800)
| Parameter Item | Official Specification |
|---|---|
| MLFB Article No. | 6AV7241-5BD37-0FA2 |
| Product Series | SIMATIC IPC 477E Industrial Panel PC |
| Display | 15″ resistive touch screen, native resolution 1280 × 800 |
| Front I/O | 1 IP65-protected front USB port |
| Rear USB Interfaces | 4 × rear USB ports |
| Industrial Ethernet | 3 × 10/100/1000 Mbps Gbit Ethernet (IE / PROFINET) |
| CPU Processor | Intel Core i5-6442EQ quad-core |
| Main Memory | 8 GB ECC industrial RAM |
| Serial Ports | 2 × configurable RS232 / RS485 DB9 interfaces |
| Expansion Slot | Without PCIe expansion slot |
| Internal Storage | 240 GB SATA solid-state drive; non-replaceable mass storage |
| Pre-installed OS | Windows 10 IoT Enterprise 2016 LTSB (64-bit MUI), compatible with Celeron / i3 / i5 CPUs |
| Runtime Software | Without preloaded SIMATIC software |
| Power Supply | 110/230 V AC industrial wide-range power unit, NAMUR-compliant |
| Power Cord | Standard EU European mains power cord included |
| Regional Certificate | No BIS certification for India AC power variant |
| Front Protection Rating | IP65 dust & splash-proof touch panel |
| Cooling System | Regulated variable-speed fan cooling with temperature monitoring |
| Mounting Method | Cabinet cutout panel mounting |
| Operating Temp Range | 0 °C ~ +50 °C horizontal installation |
| Global Certifications | CE, UL 508, cULus, GL Marine, EAC, Class A EMC (excluding India BIS) |
| Country of Manufacture | Germany |
| Code Segment | Siemens Official Definition |
|---|---|
| 6AV7241 | Base platform: SIMATIC IPC477E series 15-inch touch panel PC |
| 5BD37 | Hardware config: 15″ 1280×800 touch, Core i5-6442EQ, 8GB ECC RAM, dual RS232/485, no PCIe, 240GB SATA SSD, AC power supply |
| 0FA2 | Software & regional variant: Windows 10 IoT 2016 LTSB 64-bit MUI, no SIMATIC software, EU power cord, no India BIS certificate |
