| Item | Specification |
|---|---|
| Model | ACH580‑31‑206A‑4 |
| Product Type | Ultra‑low harmonic wall‑mount HVAC AC Drive |
| Frame Size | R8 |
| Supply Voltage | 3‑phase 380‑480 V AC |
| IEC Nominal Power(400V) | 110 kW |
| IEC Nominal Output Current | 206 A |
| UL Rating(480V) | 150 HP, 180 A |
| Light‑duty Overload | 110 % In for 60 s every 5 min |
| Heavy‑duty Overload | 150 % In for 10 s every 5 min |
| THDi | ＜3 % (Integrated ultra‑low harmonic filter) |
| Maximum Output Frequency | 500 Hz |
| Switching Frequency | 2‑12 kHz adjustable |
| Nominal Efficiency | 95.5 % |
| Analog Inputs | 2 pcs, 0(2)‑10 V / 0(4)‑20 mA |
| Analog Outputs | 2 pcs, configurable voltage / current |
| Digital Inputs | 6 pcs, 12‑24 V DC/AC, PNP/NPN configurable |
| Relay Outputs | 3 pcs, 250 V AC / 30 V DC, 2 A continuous |
| Built‑in Fieldbus | Modbus RTU, BACnet MS/TP, N2 |
| Optional Fieldbus | PROFINET IO, EtherNet/IP, Modbus TCP, EtherCAT, CANopen, DeviceNet, LonWorks |
| Safety Function | STO (Safe Torque Off), TÜV certified SIL3 / PL e |
| Enclosure Rating | IP55 / NEMA Type 12 |
| Mounting | Wall‑mount, optional flange mounting |
| Operating Ambient Temperature | ‑10 °C … +40 °C (derating above 40 °C) |
| Storage Temperature | ‑40 °C … +70 °C |
| Relative Humidity | 5‑95 % RH, non‑condensing |
| Certifications | CE, UL, cUL, BACnet BTL |
| Weight | 66 kg |
