ABB DCS880-S02-0680-05 Parameter
Full Model Number: DCS880-S02-0680-05 (Standard Configuration: DCS880-S02-0680-05X0)
Product Brand: ABB
Product Type: Industrial DC Drive Module
Core Features: Four-quadrant Operation (4-Q), Built-in Safe Torque Off (STO), Support for Multiple Fieldbus Communications, Suitable for Various Industrial Heavy-duty Scenarios
I. Model Code Interpretation
|
Code Segment
|
English Meaning
|
Detailed Description
|
|
DCS880
|
Product Series
|
ABB industrial-grade DC drive series, designed specifically for industrial heavy-duty scenarios
|
|
S02
|
Product Type + Bridge Arm
|
S0 = Standard Module (No Enclosure, Open Type); 2 = Double Anti-parallel Bridge Structure, Supporting Four-quadrant Operation
|
|
0680
|
Rated DC Current
|
Under IP00 protection level, the rated DC current is 680A DC
|
|
05
|
Rated AC Voltage
|
Suitable for 3-phase 100~525VAC input, nominal input voltage is 460VAC
|
|
X0 (Standard Configuration)
|
Wiring Method + Version
|
X = Standard Wiring Method (Suitable for H1~H7 Frames); 0 = First-generation Product Version
|
II. Electrical Parameters
|
Parameter Category
|
Parameter Name
|
Parameter Value
|
Supplementary Description
|
|
Input Side (AC)
|
Input Voltage
|
3-phase 100~525VAC (Nominal 460VAC)
|
Complies with IEC 60038 standard, suitable for general industrial 3-phase voltage range
|
|
Voltage Deviation
|
Continuous ±10%; Short-term ±15%
|
Short-term deviation duration is 0.5~30 cycles; special attention should be paid to voltage stability in regeneration mode
|
|
|
Rated Frequency
|
50/60Hz
|
Compatible with global general industrial frequency, no additional debugging required
|
|
|
Frequency Deviation
|
Static ±2%; Dynamic ±5Hz
|
Frequency change rate df/dt ≤17%/s, adapting to grid frequency fluctuations
|
|
|
Input Phase Number
|
3-phase
|
Standard configuration for industrial heavy-duty scenarios, ensuring stable power input
|
|
|
Input Current (Nominal)
|
Approx. 400A AC (460VAC Input)
|
Fluctuates slightly with input voltage, actual value depends on on-site working conditions
|
|
|
Output Side (DC)
|
Rated DC Current (ND Standard)
|
673A DC (500VAC Input)
|
Long-term operation rated value under standard working conditions, no derating required
|
|
Rated DC Current (HD Heavy-duty)
|
525A DC (500VAC Input)
|
Long-term operation rated value under heavy-duty working conditions, suitable for continuous high-load scenarios
|
|
|
Rated Power (ND)
|
400HP (Approx. 300kW)
|
Corresponds to ND standard rated current, suitable for medium and heavy-duty industrial equipment
|
|
|
Rated Power (HD)
|
300HP (Approx. 225kW)
|
Corresponds to HD heavy-duty rated current, suitable for continuous high-power equipment
|
|
|
DC Voltage Range
|
0~1000VDC
|
Adjustable according to motor requirements, suitable for different specifications of separately excited DC motors
|
|
|
Overload Capacity
|
150% Rated Current for 60s; 200% Rated Current for 10s
|
Responds to sudden load impacts, protecting equipment while ensuring operational continuity
|
|
|
Control Method
|
Four-quadrant (4-Q)
|
Supports motor forward/reverse rotation and regenerative energy feedback, energy-saving and suitable for complex working conditions
|
|
|
Loss and Efficiency
|
Power Loss
|
1760W
|
Rated loss under standard working conditions, actual loss varies with load
|
|
Operating Efficiency
|
≥98% (Rated Load)
|
High efficiency and energy saving, reducing energy waste and operating costs
|
|
|
Excitation Control
|
Excitation Control Method
|
Built-in Excitation Control
|
Suitable for separately excited DC motors, supporting field commutation function
|
|
Excitation Current Range
|
2~30A DC
|
Adjustable according to motor excitation requirements, ensuring stable motor operation
|
III. Mechanical and Environmental Parameters
|
Parameter Category
|
Parameter Name
|
Parameter Value
|
