This is a detailed English parameter sheet for the ABB ACS800‑04‑0050‑3 (single‑drive module) with options E200, K454, Q967, covering core electrical ratings, option specs, communication, physical‑environmental data, and compliance for industrial motor control applicationsABB Group.
Core Electrical Ratings
| Parameter | Value | Notes |
|---|---|---|
| Input Voltage (U₁) | 3AC 380–480 V (50/60 Hz) | 3rd voltage code; tolerance ±10% |
| Rated Input Current (I₁ₙ) | 50 A (rms, 3‑phase) | At 400 V rated voltage |
| Rated Output Power (Pₒᵤₜₙ) | 37 kW (at 400 V, 50 Hz) | DTC control; 98% nominal efficiency |
| Rated Output Current (Iₒᵤₜₙ) | 50 A (rms, 3‑phase) | Continuous at 40°C ambient |
| Output Voltage (Uₒᵤₜ) | 0–480 V (3‑phase, variable) | Matches input voltage range |
| Output Frequency (fₒᵤₜ) | 0–300 Hz (standard); ±300 Hz (optional) | Speed/torque control range |
| DC Link Voltage (U<sub>DC</sub>) | ~540 VDC (unloaded); ~510 VDC (loaded) | Diode rectifier output |
| Overload Capacity | 110% Iₙ for 60 s; 150% Iₙ for 1 s | Per ABB single‑drive design specs |
| Power Loss (P<sub>loss</sub>) | ~1.2 kW (typical, at rated load) | Includes module + option power draw |
| Auxiliary Supply (Uₐᵤₓ) | 24 VDC (19.2–28.8 VDC) | Control circuit power |
| Auxiliary Current (Iₐᵤₓ) | 5 A (max) | For logic, I/O, and cooling fans |
Option Specifications (E200+K454+Q967)
| Option | Type | Key Parameters | Function |
|---|---|---|---|
| E200 | EMC Filter | EN 61800‑3 C2 compliance; 150 kHz–30 MHz attenuation | Reduces conducted/radiated emissions |
| K454 | Pulse Encoder Interface | 5 V/24 V encoder supply; 1024 ppr max resolution | Closed‑loop speed/torque control |
| Q967 | Safety Functions | SIL 2 (IEC 61508); STO (Safe Torque Off) | Safe motor stop without power removal |
Communication & Control
| Parameter | Value | Details |
|---|---|---|
| Control Method | Direct Torque Control (DTC) | Speed/torque control with/without encoder |
| Digital Inputs | 6 (programmable, 24 VDC) | 24 VDC, -15% to +20% tolerance |
| Analog Inputs | 3 (0/4–20 mA or 0/2–10 V) | 12‑bit resolution; galvanically isolated |
| Analog Outputs | 2 (0/4–20 mA) | Max load impedance ≤700 Ω |
| Relay Outputs | 3 (programmable) | 8 A at 24 VDC/250 VAC; 0.4 A at 120 VDC |
| Fieldbus Options | Profibus DP, Modbus RTU, CANopen | K454 enables encoder feedback |
Physical & Environmental
| Parameter | Value | Limits |
|---|---|---|
| Dimensions (H×W×D) | 620 × 400 × 564 mm | Cabinet‑mounted profile |
| Weight | 45 kg | Steel housing; IP20 rear protection |
| Protection Class | Front: IP00; Rear: IP20 | Cabinet‑mount only (indoor use) |
| Ambient Temp (Operation) | 0–40°C | Derate 1%/°C above 40°C (max 50°C) |
| Ambient Temp (Storage) | -40–70°C | No condensation |
| Relative Humidity | 5–95% (non‑condensing) | Operation/storage |
| Altitude | ≤ 1000 m | Derate 1%/100 m above 1000 m |
| Vibration/Shock | IEC 60068‑2‑6 (vibration); IEC 60068‑2‑27 (shock) | 10–500 Hz, 0.5 g (vibration); 15 g (shock, 11 ms) |
Protection & Compliance
| Feature | Details | |
|---|---|---|
| Overvoltage | Clamping at 1.3×U<sub>DC</sub> | Transient surge protection |
| Overcurrent | Electronic current limiting | Trips at >150% Iₙ (sustained) |
| Short‑Circuit | Fuse‑protected input (optional) | 100 kA SCCR (400 V) |
| Standards | CE, UL 508C, cUL, IEC 61800‑5‑1 | Industrial safety/EMC compliance |
