ACS800-01-0060-7+B056+E200+P901
| Item | Specification |
|---|---|
| Full Model | ACS800-01-0060-7+B056+E200+P901 |
| Product Category | ABB ACS800 Series Wall-mounted Industrial AC Variable Frequency Drive |
| Supply Voltage Range | 3-phase 525–690 V AC ±10%, 50/60 Hz |
| Continuous Output Current (Light Duty) | 57 A |
| Heavy Duty Rated Output Current | 49 A |
| Rated Motor Power (Light Duty @690V) | 55 kW |
| Rated Motor Power (Heavy Duty @690V) | 45 kW |
| Core Control Algorithm | Direct Torque Control (DTC) |
| Default Switching Frequency | 3 kHz (adjustable 1–10 kHz) |
| Overload Capability | 110% of rated current continuous; 150% of heavy-duty current for 1 minute per 10-minute cycle |
| Enclosure Rating (+B056 Option) | IP55 / NEMA 12 (dust-tight, protected against water splashes from all directions) |
| EMC Compliance (+E200 Option) | Category C3 EMC filter for TN grounded power systems, meets IEC 61800-3 C3 requirements |
| PCB Protection (+P901 Option) | Conformal coated printed circuit boards for humid, dusty or corrosive industrial environments |
| Standard Built-in Components | Integrated brake chopper, CDP312R alphanumeric LCD control panel |
| Onboard Communication | Modbus RTU via built-in RS485 interface |
| Rated Efficiency | ≥98% at full rated load |
| Cooling Method | Forced air cooling with temperature-controlled variable-speed fan |
| Operating Ambient Temperature | -15 °C to +50 °C (no power derating below 40 °C) |
| Mechanical Frame Size | R5 |
| Overall Dimensions (H×W×D) | 830 mm × 293 mm × 358 mm |
| Net Weight | 32 kg |
| Compliance Certifications | CE, UL, cUL, IEC 61800-5-1 (safety), IEC 61800-3 (EMC) |
