Technical specifications for 22A-D1P4N104
| Brand | Allen-Bradley |
|---|---|
| Part Number/Catalog No. | 22A-D1P4N104 |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Family: | PowerFlex 40 |
| Input Voltage: | 380-480VAC |
| Output Voltage: | 0-480VAC |
| Output Current: | 1.4 A |
| Output Power: | 0.4 kW or 0.5 HP |
| I/O: | Discrete Inputs: Four (4) Sink / Source Discrete Outputs: One (1) N.O.; One (1) N.C. Contacts; Two (2) Digital / Optocoupler Analog Input: Two (2) Unipolar 0-10VDC; 0- 20mA; One (1) bipolar +/-10VDC Analog Output: One (1) Analog Input 0-10VDC; 0- 20mA |
| Installation: | Panel Mount / DIN Rail |
| Zero Stacking: | Supported |
| Enclosure Rating: | IP20 / NEMA UL Type Open |
| Control Method: | Volts per Hertz (V/Hz), Sensorless Vector Control (SVC), |
| StepLogicTechnology: | Integrated |
| Integrated safety: | Safe-Torque Off (STO) functionality |
| Built-in communication port: | Ethernet I/P / RS485 |
| Product Line | PowerFlex 4 |
| Amperage | 1.4 |
| Enclosure Type | IP20/UL (Open) |
| Filter | Without CE Compliant Filter |
| Phases | 3-Phase |
| Wattage | 3.7 Kilowatt |
| Input Type | Keypad |
| Display | Light-Emitting Diode (LED) |
| Horsepower | 0.5 Horsepower |
| Input Power | 380 to 480 Volts AC |
| Brake Drive | Brake Drive |
