2711-K14C20
The Allen-Bradley/Rockwell Automation 2711-K14C20 terminal is an operator interface terminal from the Allen-Bradley Panelview 1400 series. It is controlled by a keypad that includes number keys for entering data values, arrow keys for navigation, and programmable function keys. The 2711-K14C20 operator interface terminal can support color graphics. Its display screen is 14 inches wide. The 2711-K14C20 operator interface terminal supports AC voltage and the Ethernet network.
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711-K14C20 |
| Power Type | AC |
| Supply Voltage Limit | 85-264 Volts; 43-63 Hertz |
| Power Consumption | 200 VA max |
| Comm Port | Ethernet |
| Total Application Flash Memory | 1008 Kbytes |
| Operating Shock | 15 g |
| Non-Operating Shock | 30 g |
| Operating Temperature | 32-131 F (0-55 C) |
| Dimensions | 13.97 x 19.0 x 15.53 in (355 x 483 x 394 mm) |
| Display Dimensions | 10.0 x 7.5 in (255 x 191 mm) |
| Weight | 44.75 lbs (20.3 kg) |
| Method of Input | Keypad |
