2711P-T15C4A8 Allen Bradley PanelView Plus 6 Terminal1500 Color Touch Panel
- Product Selection: PanelView Plus 6, For more information, please visit the following link:, PanelView Plus 6 Graphic Terminals Home Page
- Monitor Size: 15-inch TFT Display, 1500 Color Model, *304 x 228 mm (12.0 x 9.0 in) Display Area (WxH)
- DisplayType: Color (TFT)
- Input Type: Touch Screen, 305 x 391 mm (12.0 x 15.4 in) Cutout Dimensions
- Communication: Standard Communication – Ethernet & RS-232, *The Ethernet port supports EtherNet/IP and Ethernet options using KEPServer drivers, *The RS-232 port supports DF1 serial, DH-485 serial, and multi-vendor serial drivers.
- Power: AC Input, 85…264V AC, 47…63 Hz
-
- Description: PanelView Plus 6 Terminal | 1500 Color Touch Model
- Flash/RAM or Operating System: Windows CE 6.0
- Screen Size: – No Value
- Model: PVP6 Standard Edition
- Network Media: (1), Male RJ45 to RJ45 Patchcord, Unshielded Twisted Pair, Teal TPE Cable, 1.9 m, 1585J-M8TBJM-1M9
-
Part Number: 2711P-T15C4A8 Product Line: Panelview 6 Plus Display Size: 15 inch Display Color: Color Input Type: Touch screen Communication: Ethernet and RS-232 Input Power: 100-240 VAC Software: FactoryTalk View Machine Edition Memory: 512 MB RAM Backlight Replacement: 2711P-RL15C Communication Cable(s): 2711-NC13 Shipping Weight: 13 lbs. Shipping Dimensions: 20 x 14 x 8 in Series: Series A and Series B Firmware: 6.00-8.10
