1756IB16D | 1756-IB16D
Allen-Bradley 1756-IB16D Controllogix 16-Point D/I Module
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-IB16D |
| Series | ControlLogix |
| Module Type | Digital DC Input Module |
| Inputs | 16 Diagnostic Inputs |
| Input Voltage | 12-24 Volts DC Sink |
| Operating Voltage Range | 10-30 Volts DC |
| Input Delay Time | 4 milliseconds plus selected filter time |
| Minimum Operating Current | 2 milliamperes at 10 Volts DC |
| Maximum Operating Current | 13 milliamperes at 30 Volts DC |
| Maximum Input Current, Off-State | 1.5 milliamperes per point |
| Power Dissipation (Max) | 5.8 Watts at 60 degrees Celsius |
| Backplane Current at 5 Volts | 150 milliamperes |
| Removeable Terminal Block(s) | 1756-TBCH, 1756-TBS6H |
| UPC | 10612598164490 |
