1756OV32E | 1756-OV32E
Output Module,ControlLogix,DC Digital,32 Point,10-30VDC
Allen-Bradley 1756-OV32E Controllogix 32-Point D/O Module
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-OV32E |
| Series | ControlLogix |
| Module Type | Electronically Fused Sinking Output Module |
| Outputs | 32-Point Electronically Fused |
| Voltage | 12-24 Volts DC |
| Operating Voltage Range | 10-30 Volts DC |
| Maximum Output Current Rating-Point | 0.5 Amps at 50 Celsius, 0.35 Amps at 60 Celsius |
| Maximum Output Current Rating-Module | 16 Amps at 50 Celsius, 10 Amps at 60 Celsius |
| Power Dissipation (Max) | 5.88 Watts at 60 Celsius |
| Backplane Current at 5 Volts | 390 milliamps |
| Removeable Terminal Block(s) | 1756-TBCH, 1756-TBS6H |
| Isolation Voltage | 50 Volts Continuous |
