2099-BM07-S — Kinetix 7000 30kW Servo Drive
ALLEN-BRADLEY
Drive, 47.7A, Kinetix 7000 High Power Servo Drive, Safe Torque Off
| Parameter | Specification |
|---|---|
| Catalog Number | 2099-BM07-S |
| Drive Family | Kinetix 7000 High Power Servo Drive |
| Continuous Power Output, Nom | 30 kW (40 Hp) |
| AC Input Voltage | 342…528V AC rms, three-phase (380…480V nom) |
| AC Input Frequency | 47…63 Hz |
| Main AC Input Current, Nom (rms) | 47.7 A |
| Main AC Input Current, Max Inrush (A peak) | 18 A |
| DC Input Voltage | 450…750V DC |
| DC Input Current | 55.7 A |
| Control Power Input Voltage | 18…30V DC (24V DC, nom) |
| Control Power DC Input Current, Nom (rms) | 3.3 A |
| Control Power DC Input Current, Max Inrush (rms) | 6.0 A |
| Continuous Output Current (rms) | 52 A |
| Continuous Output Current (0-pk) | 73 A |
| Peak Output Current (rms) – 3 s duration | 80 A |
| Peak Output Current (rms) – 60 s duration | 60 A |
| Peak Output Current (0-pk) – 3 s duration | 113 A |
| Peak Output Current (0-pk) – 60 s duration | 84.8 A |
| PWM Frequency | 4 kHz |
| Total Capacitance | 2400 µF |
| Bus Overvoltage Trip | 800V DC |
| Efficiency | 97.5% |
| Recommended Fuse | FWJ-100A |
| Short-Circuit Current Rating (SCCR) | 200,000 A (rms) symmetrical |
