2099-BM08-S — Kinetix 7000 37kW Servo Drive
ALLEN-BRADLEY
Drive, 59.6A, Kinetix 7000 High Power Servo Drive, Safe Torque Off
| Parameter | Specification |
|---|---|
| Catalog Number | 2099-BM08-S |
| Series | Kinetix 7000 High Power Servo Drive |
| Description | Drive, 59.6 A, Kinetix 7000 High Power Servo Drive, Safe Torque Off |
| AC Input Voltage | 342…528V AC rms three-phase (380…480V nom) |
| AC Input Frequency | 47…63 Hz |
| Main AC Input Current (Nom rms) | 59.6 A |
| Main AC Input Inrush Current (Peak) | 18.0 A |
| DC Input Voltage | 450…750V DC |
| DC Input Current | 69.7 A |
| Control Power Input Voltage | 18…30V DC (24V DC, nom) |
| Control Power DC Input Current (Nom) | 3.3 A |
| Control Power Max Inrush Current | 6.0 A |
| Continuous Output Current (rms) | 65.0 A |
| Continuous Output Current (0-pk) | 92.0 A |
| Peak Output Current (rms) – 3 s duration | 104 A |
| Peak Output Current (rms) – 60 s duration | 78.0 A |
| Peak Output Current (0-pk) – 3 s duration | 147 A |
| Peak Output Current (0-pk) – 60 s duration | 110 A |
| Continuous Power Output (Nom) | 37 kW / 50 Hp |
| Total Capacitance | 3000 µF |
| Short-Circuit Current Rating (SCCR) | 200,000 A (rms) symmetrical |
| PWM Frequency | 4 kHz |
| Velocity Loop Bandwidth | 500 Hz |
| Current Loop Bandwidth | 1300 Hz |
| Bus Overvoltage Trip | 800V DC |
| Bus Undervoltage Trip | 275…560V DC |
| Efficiency | 97.5% |
| DC Bus Discharge Time | 3 minutes after removal of main AC power |
| Max Power Cycles/Minute (AC Line) | 4 per minute (pre-charge provided by drive) |
| Max Power Cycles/Minute (DC Bus) | 2 per minute |
| Recommended AC Line Fuse (Bussmann) | LPJ-125SP |
| Recommended DC Bus Fuse (Bussmann) | FWJ-125A |
| Approximate Weight | 19.05 kg (42.0 lb) |
