2099-BM11-S — Kinetix 7000 Servo Drive
ALLEN-BRADLEY
Drive, 169A, Kinetix 7000 High Power Servo Drive, Safe Torque Off
| Parameter | Specification |
|---|---|
| Catalog Number | 2099-BM11-S |
| Product Family | Kinetix 7000 High Power Servo Drive |
| Lifecycle Status | Discontinued (as of December 31, 2023) |
| Replacement Product | 2198-S263-ERS3 (Engineering Replacement) |
| AC Input Voltage | 342…528V AC rms, three-phase (380…480V nom) |
| AC Input Frequency | 47…63 Hz |
| Main AC Input Current (Nom rms) | 169 A |
| Max Inrush Current (A peak) | 141 A |
| DC Input Voltage | 450…750V DC |
| DC Input Current | 204 A |
| Control Power Input Voltage | 18…30V DC (24V DC, nom) |
| Control Power DC Input Current (Nom rms) | 3.3 A |
| Control Power DC Input Current (Max Inrush rms) | 6.0 A |
| Continuous Output Current (rms) | 180 A |
| Continuous Output Current (0-peak) | 254 A |
| Peak Output Current (rms, 3 s duration) | 312 A |
| Peak Output Current (rms, 60 s duration) | 234 A |
| Peak Output Current (0-peak, 3 s duration) | 441 A |
| Peak Output Current (0-peak, 60 s duration) | 331 A |
| Continuous Power Output (nom) | 112 kW (150 Hp) |
| Total Capacitance | 8400 µF |
| Short-Circuit Current Rating (SCCR) | 200,000 A (rms) symmetrical |
| Efficiency | 97.5% |
| Bus Overvoltage Trip | 800V DC |
| Bus Undervoltage Trip | 275…560V DC |
| PWM Frequency | 4 kHz |
| Velocity Loop Bandwidth | 500 Hz |
| Current Loop Bandwidth | 1300 Hz |
| DC Bus Discharge Time | 3 minutes (after removal of main AC power) |
| Power Cycles per Minute (AC Line) | 4 |
| Power Cycles per Minute (DC Bus) | 2 |
| Recommended AC Line Fuse (Bussmann) | LPJ-400SP |
| AC Fuse Range (Dual-Element Time Delay) | 225…400 A rms |
| AC Fuse Range (Non-Time Delay) | 225…600 A rms |
| Motor Circuit Protector (Max) | 250 A rms |
| Recommended DC Common Bus Fuse (Bussmann) | FWJ-500A |
| Recommended DC Common Bus Fuse (Mersen) | HSJ400 |
| Power Dissipation at 100% Rated Output | 2125 W |
| Power Dissipation at 50% Rated Output | 1275 W |
| Ambient Temperature (Operational) | 0…50 °C (32…122 °F) |
| Relative Humidity (Operational) | 5…95% (noncondensing) |
| Altitude (Operational) | 1000 m (3281 ft) max without derating; up to 3000 m (9843 ft) with derating |
| Vibration (Operational) | 5…55 Hz @ 0.35 mm double amplitude; 55…500 Hz @ 2.0 g peak |
| Shock (Operational) | 15 g, 11 ms half-sine pulse |
| Approximate Weight | 71.4 kg (157.5 lb) |
| Dimensions (H x W x D) | Approx. 977.1 x 429.2 x 282.7 mm (38.47 x 16.90 x 11.13 in) |
