20F11ND2P1JA0NNNNN — PowerFlex Air Cooled 753 AC Drive
Allen‑Bradley PowerFlex 753 AC Drive, with Embedded I/O, Standard Protection, Forced Air, AC Input with DC Terminals, IP20/IP00, NEMA/UL Open Type, 2.1 Amps, (Fr1 1HP ND, 0.5HP HD/Fr2 1HP ND, 1HP HD), 480 VAC, 3 PH, Frame 2, Filtered, CM jumper installed (preferred), DB Transistor, Blank (No HIM)
| Catalog Number | 20F11ND2P1JA0NNNNN |
| Product Series | Allen‑Bradley |
| Product type | PowerFlex 753 |
| Product Series | AC Drive |
| I/O Configuration | Embedded I/O |
| Enclosure Type | Standard Protection |
| Cooling Method | Forced Air |
| Input Configuration | AC Input with DC Terminals |
| Protection Rating (Chassis) | IP20 / IP00 |
| NEMA/UL Type | NEMA/UL Open Type |
| Rated Current | 2.1 Amps |
| Power Ratings (Frame 1) | 1 HP Normal Duty (ND) |
| Power Ratings (Frame 2) | 1 HP Normal Duty (ND) / 1 HP Heavy Duty (HD) |
| Input Voltage | 480 VAC |
| Phase | 3‑Phase |
| Frame Size | Frame 2 |
| EMC Filtering | Filtered (with built‑in EMC filter) |
| Common Mode (CM) Jumper | Installed (preferred configuration) |
| Dynamic Braking | DB Transistor (integrated) |
| Human Interface Module (HIM) | Blank (no HIM supplied) |
