Allen Bradley 5069-OBV8S Compact5000 DC Safety Output Module
| Technical specifications for 5069-OBV8S | |
| Brand | Allen-Bradley |
| Series | Compact 5000 I/O |
| Manufacturer | Rockwell Automation |
| Module Type | Safety DC Output module |
| No. of Outputs | Eight (8) DC safety output channels |
| Output Voltage signal, nominal | 24VDC |
| Output Voltage Signal range | 17.5-32VDC |
| Output current rating | 1:00 AM |
| Safety Integrity Level | SIL CL3, PLe, Cat. 4 |
| Safety reaction time (SRT) | 4.5 ms |
| Pulse width, min | 400 µs |
| No. of output groups | Two (2) |
| Field power loss detection | Yes (per point) |
| Reverse voltage protection | Yes |
| Part Number | 5069-OBV8S |
| Type | Output module |
| Output type | 8-point output |
| Output voltage | 8-32 Volts DC |
| Output rating | 1 Ampere per channel |
| Isolation voltage | 250 Volts |
| Operating temperature | 0 to 50 degrees Celsius |
| Orientation | Horizontal or Vertical |
| Wire type | Copper |
| Structure | Conformal coating |
