2711P-B7C22A9P | Allen-Bradley PanelView Plus 7 Color Touch 7″, Ethernet, AC
2711P-B7C22A9P
| Technical specifications for 2711P-B7C22A9P | |
| Brand | Allen-Bradley |
| Display Size | 6.5 inches. |
| Part Number/Catalog No. | 2711P-B7C22A9P |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Family: | PanelView Plus 7 Performance terminals |
| Operator Input: | Touch / Keypad |
| Display Type: | Color active-matrix TFT |
| Display Area: | 304 x 228 mm (12.0 x 9.0 in.) |
| Resolution: | 640 x 480 VGA, 18-bit color graphics |
| Touch: | Analog resistive Actuation: 1 million presses; operating force: 100 g |
| System Memory: | 1GB RAM, 512 MB nonvolatile memory (approx. 80 MB free user memory) |
| Communication ports: | Two (2) Ethernet, Three (3) USB host |
| Power Consumption: | 105VA |
| Backlight: | White light-emitting diode, solid state Life: 50,000 h min at 40 °C (104 °F) to half-brightness, backlight is not replaceable |
| Product Line | Panelview Plus 7 |
| Input Type | Touchscreen/Keypad |
| Display Color | Color |
| Memory | 512 Mb |
| Input Voltage | 100-240VAC |
| Backlight | LED |
| Weight | 3.25 LBS |
