| Category | Verified Specification 22C-D060N103 |
|---|---|
| Catalog Number (MPN) | 22C-D060N103 |
| Brand | Allen‑Bradley / Rockwell Automation |
| Product Family | PowerFlex 400 Adjustable Frequency AC Drive |
| Country of Origin | Malaysia |
| Rated Power | 40 HP / 30 kW |
| Rated Output Current | 60 A |
| Input Voltage | 3‑Phase 480 V AC (380–480 V ±10%), 50/60 Hz |
| Frame Size | Frame D |
| Enclosure Type | Panel Mount, IP20 / UL Open‑Type |
| EMC Filter | Not Filtered (no built‑in EMC filter) |
| Operator Interface | Integrated Fixed Local Keypad |
| Onboard Communication | RS485 (Modbus RTU, DF1 protocol) |
| Optional Communication Slots | Supports Devicenet, Profibus, Ethernet/IP adapter modules |
| Output Frequency Range | 0 … 400 Hz |
| Control Method | V/Hz control; Sensorless Vector Control |
| Standard Functions | Motor overload protection, DC braking, skip frequencies, fault logging |
| Power Consumption & Losses | Per Rockwell standard frame D power loss characteristic |
| Mechanical Dimensions | W 267 mm × H 432 mm × D 208 mm |
| Net Weight | Approx. 14.1 kg |
| Mounting | Vertical panel mounting inside control cabinet |
| Protection Class | IP20, indoor cabinet installation only |
| Operating Environment | Operating temperature: 0 °C … +40 °C (full rating); derate above 40°C
Humidity: 5–95% non‑condensing, Pollution Degree 2 |
| Certifications | CE, UL/cULus compliant |
| Lifecycle Status | Obsolete / End of production, available only as legacy spare part |
| Packaging Note | Original single unit export carton; exact outer carton dimensions not published on official datasheet. |
