20F11ND027AA0NNNNN — PowerFlex Air Cooled 753 AC Drive
753 AC Packaged Drive,Air Cooled,Open Type,480 VAC, 3 PH,27 Amps, 20HP ND, 15HP HD,AC In w/ Prchg, see More Info,Frame 3,EMC Filter,DB Transistor,Blank (No HIM),No Option,No Option,No Option,No Option,No Option,Carton & Documents
| Technical specifications for 20F11ND027AA0NNNNN | |
| Manufacturer | Rockwell Automation |
| Part Number/Catalog No. | 20F11ND027AA0NNNNN |
| Brand | Allen-Bradley |
| Series | PowerFlex 753 |
| Enclosure Rating | IP20/IP00, NEMA/UL Type Open |
| Voltage Rating | 480VAC/650VDC |
| Continuous Output Power, ND | 20 HP |
| Continuous Output Current, HD | 22 Amperes |
| Continuous Output Power, HD | 15 HP |
| DC Filtering | Yes |
| Default CM Cap Connection | Jumper removed |
| Internal Resistor | No |
| Human Interface Module (HIM) | Not Included |
| Premiere integration: | Supported |
| Optional communication protocols: | CIP Motion; ControlNet (Coax or Fiber); DeviceNet; RS485 DFI; PROFIBUS DP; Modbus/TCP; HVAC (Modbus RTU, FLN P1, Metasys N2); Bluetooth; CANopen and LonWorks. |
| Control Methods: | Vector Control w/FORCE Technology with and without an encoder feedback; Sensorless Vector Control (SVC); Volts per Hertz control and Permanent Magnet Motor control but only the interior component |
| Voltage Class | 480 AC Volts |
| Output Current | 27 Amperes |
| Phase Count | Three |
| Frame Size | 3 |
| Enclosure Type | IP00 (IP20 NEMA) |
| EMC Filtering Options | Filtered, No CM Jumper |
| Input Type | AC Input with DC Terminals |
| Dynamic Breaking | DB Transistor |
| Weight | 26.1 lbs |
| Dimensions | 17.87 x 7.48 x 8.35 in |
