Configuration Key (Catalog Number Breakdown)
The part number 20F1AND302JA0NNNNN breaks down as follows to confirm the above specifications:
-
20F: PowerFlex 753
-
1: 480V AC, 3-Phase
-
A: Open Type (IP20)
-
N: No DC Terminals
-
D: AC Input with Precharge
-
302: 302 Amps (Rated Current)
-
J: Frame Size 7
-
A: Filtered, CM Jumper Installed
-
0: Blank Cover (No HIM)
-
NNNNN: Standard/No Modifications
PowerFlex 753 AC Drive, with Embedded I/O, Standard Protection, Forced Air, AC Input with Precharge, no DC Terminals, Open Type, 302 Amps, 250HP ND, 200HP HD, 480 VAC, 3 PH, Frame 7, Filtered, CM jumper installed (preferred), DB Transistor, Blank (No HIM)
| Parameter | Specification | Notes / Source |
| Product Line | PowerFlex 753 | Standard AC Drive |
| Enclosure Type | IP20 / NEMA Open Type | For controlled environments with ventilation |
| Input Voltage | 480V AC, 3-Phase | 3-phase operation |
| Rated Current | 302 Amps | Continuous output current |
| Normal Duty Rating (ND) | 250 HP (185 kW) | Typical for variable torque loads (Pumps/Fans) |
| Heavy Duty Rating (HD) | 200 HP (150 kW) | Typical for constant torque loads (Conveyors) |
| Frame Size | Frame 7 | Physical construction size |
| Cooling Method | Forced Air Cooled | Internal fan cooling |
| HIM (Interface) | None (Blank) | No local keypad included (sold separately) |
| Filtering | Filtered / EMC compliant | Includes built-in EMC filtering |
| Internal Precharge | Yes | Standard AC input with precharge circuit |
| DC Terminals | No | No DC input terminals (AC input only) |
| Common Mode Jumper | Installed | For mitigating bearing currents |
| Weight | ~68 kg (150 lbs) | Shipping/Unit weight |
| Operating Temp | 0 °C to 40 °C | Ambient temperature rating |
| Max Altitude | 1000 m (3300 ft) | Without derating |
