Catalog Number Breakdown (20F1AND361JN0NNNNN):
-
20F: PowerFlex 753
-
1: 480V AC / 600V Class
-
A: Open Type (IP00)
-
N: No DC Terminals
-
D: Filtered / CM Jumper Installed
-
361: 361 Amps ND Rating
-
J: Blank PCB (No HIM)
-
N: No Communication Card
-
0: Standard (No Brake IGBT)
-
NNNNN: Standard Hardware
PowerFlex 753 AC Drive, with Embedded I/O, Standard Protection, Forced Air, AC Input with Precharge, no DC Terminals, Open Type, 361 Amps, 300HP ND, 250HP HD, 480 VAC, 3 PH, Frame 7, Filtered, CM jumper installed (preferred), None, Blank (No HIM)
| Technical Specifications for Catalog Number 20F1AND361JN0NNNNN | |
| Parameter | Specification |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AND361JN0NNNNN |
| Drive Type | High Performance AC Drive |
| Enclosure (Protection) | Open Type (IP00/NEMA Open) |
| Frame Size | Frame 7 |
| Cooling Method | Air Cooled |
| Electrical & Power Ratings | |
| Parameter | Specification |
| Input Voltage | 480V AC (3-Phase) / 650V DC Bus |
| Rated Frequency | 60 Hz |
| Normal Duty (ND) | 300 HP / 361 Amps |
| Heavy Duty (HD) | 250 HP / 302 Amps |
| Filtering | Filtered (EMC compliance) |
| Precharge | Included |
| DC Terminals | Not included in this configuration |
| Physical & Environmental | |
| Parameter | Specification |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Storage Humidity | 80% maximum (non-condensing) |
| Operating Altitude | 1000 m (3,300 ft) max without derating |
| Approx. Weight | 150 lbs (68 kg) |
