1783-US5TG
Stratix 2000 5TG unmanaged switch
| Technical specifications for 1783-US5TG | |
| Manufacturer | Allen Bradley |
| Product Type | Stratix 2000 managed switch |
| Product Line | Stratix 2000 |
| Part Number | 1783-US5TG |
| UPC | 884951981454 |
| Weight | 1.00 lbs (0.45 kg) |
| Product Family | Stratix Ethernet Switch |
| No. of copper ports | Five (5) copper ports |
| Transmission speed | 10 / 100 / 1000 mbps |
| No. of fiber ports | None |
| Supply voltage range | 12-48V DC, 18-30V AC, 50/60 Hz |
| Nominal Supply voltage | 24 VAC / VDC |
| Power consumption | 4.5 Watts |
| Inrush Current | 0.33 A |
| Total Ports | 5 |
| RJ45 Ports | 5 Gigabit Ethernet |
| SFP Ports | 0 |
| Max Inrush Current | 0.33 A |
| Power Input | 24V (12 to 48V DC, 18 to 30V AC, 50/60 Hz), SELV |
| Max Power Consumption | 4.5 W |
| Nom Current | DC 250 mA; AC 500 mA |
| Max Current | DC 510 mA; AC 1020 mA |
| Wire Size: Ground Connection | 2.5 mm2 (14 AWG) Copper Wire Suitable for 187 degrees F (86 degrees C) Above Surrounding Ambient Temperature Outside the Enclosure, with Suitable Ring Terminal |
| Wire Size: DC Power Connection | 4.5 to 5.0 in-lb (0.50 to 0.56 N-m) |
| Max Ground Terminal Screw Torque | Open-Style/None |
| Enclosure Type Rating | 4.51 x 3.02 x 1.17 in (114.5 x 76.8 x 29.6 mm) |
| Connector type | RJ45 |
| Wire type | Category 5 (Cat5) based on ISO/IEC 24702; Category 5e (Cat5e) in compliance with TIA 568-B.1 |
| Mounting | DIN Rail |
| Operating shock | 15 g |
| Operating Temperature | -10 °C – +60 °C (-4 °F – +140 °F) |
| Temperature, ambient, max | 60 °C (140 °F) |
| Temperature, surrounding air, max | 60 °C (140 °F) |
