1783-US4T1H
ALLEN-BRADLEY Stratix 2000 4+1 unmanaged port switch
| Technical specifications for 1783-US4T1H | |
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | Stratix 2000 |
| Part Number | 1783-US4T1H |
| UPC | 885630533971 |
| Weight | 3.00 lbs (1.36 kg) |
| Total Ports | 5 |
| RJ45 Ports | 4 Fast Ethernet |
| SFP Ports | 1 Fast Ethernet Singlemode Preinstalled Fiber SFP Module |
| Max Inrush Current | 1.69 A |
| Power Input | 24 V (12-48 V DC, 18-30 V AC, 50/60 Hz), SELV |
| Max Power Consumption | 3.4 W |
| Nom Current | DC 180 mA; AC 360 mA |
| Max Current | DC 380 mA; AC 750 mA |
| Wire Size: Ground Connection | 2.5 mm2 (14 AWG) Copper Wire Suitable for 187 degree F (86 degrees C) Above Surrounding Ambient Temperature Outside the Enclosure, with Suitable Ring Terminal |
| Wire Size: DC Power Connection | 4.5 x 5.0 in -lb (0.50 x 0.56 N – m) |
| Power Terminal Screw Torque | 8.05 in -lb |
| Max Ground Terminal Screw Torque | Open-Style/None |
| Enclosure Type Rating | 4.51 x 3.02 x 1.17 in (114.5 x 76.8 x 29.6 mm) |
