1783-RMS10T
Stratix 8300 10 Port Ethernet Switch
| Technical Specifications for 1783-RMS10T | ||
| Parameter | Specification | Notes / Source |
| Manufacturer | Allen‑Bradley / Rockwell Automation | |
| Series | Stratix 8300 Managed Switch | Stratix 8000 series also mentioned |
| Product Type | Industrial Ethernet Switch | |
| Network Layer | Layer 3 (Managed) | Supports routing capabilities |
| Total Ports | 10 | Copper RJ45 |
| Port Speed | 10/100 Mbps or 1 Gbps [*] | Most sources state 10/100 Mbps; one claims 1 Gbps |
| Power Input | 18–60 VDC | Redundant inputs supported |
| Power Dissipation | 15.7 W (Max) | |
| Inrush Current | 2 A | |
| Operating Temp. | 0 °C to 60 °C | Standard rating |
| Extended Temp. [*] | -40 °C to 75 °C | Listed by some industrial suppliers |
| Insulation Voltage | 75 V (Tested) | |
| Alarm Relay | 30 VDC / 1 A | |
| Mounting | Vertical / DIN Rail | Specific orientation required for cooling |
| Enclosure/Protection | Conformal Coated PCB | IP20 or IP30 rating |
