1794-OB16D
Flex 16 Point Digital Output Module
| Technical specifications for 1794-OB16D | |
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Digital Output Module w/ Diagnostics |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-OB16D |
| UPC | 612598305964 |
| Weight | 0.25 lbs (0.11 kg) |
| Outputs | 16 Nonisolated |
| Output Voltage nom. | 24V DC |
| Output Current Rating | 8.0A |
| On-state Current max. | 500mA per Channel |
| Off-state Leakage max. | 0.5mA |
| Output Signal Delay | 0.5 ms |
| Isolation Voltage | 50V |
| Flexbus Current | 60mA @ 5V DC |
| Power Dissipation | 4.8W @ 31.2V DC max. |
| Thermal Dissipation | 16.4 BTU/hr. @ 31.2V DC max. |
