6SE7021-0TP50 SIMOVERT MASTERDRIVES MOTION
Product Family: SIMOVERT MASTERDRIVES MC (Motion Control) Compact Plus Inverter
Core Electrical Parameters
表格
| Parameter | Value | Notes |
|---|---|---|
| Model | 6SE7021-0TP50 | DC-fed motion control inverter |
| DC Input Voltage | 510–650 V DC | Nominal 600 V DC |
| Output Voltage | 0–380/480 V AC, 3‑phase | Adjustable, matches motor voltage |
| Rated Output Current | 10.2 A | Continuous, 3‑phase |
| Peak Output Current | 30 A | Short‑time (10 s) overload |
| DC Link Rated Current | ~11 A | Intermediate circuit rating |
| Rated Motor Power | 4.0 kW (5.4 HP) | At 400 V, 4‑pole induction motor |
| Output Frequency Range | 0–400 Hz | Standard; up to 650 Hz with option |
| Control Modes | V/F, Sensorless Vector, Closed‑Loop Vector (encoder), Torque Control | High‑dynamic motion control |
| Switching Frequency | 2–16 kHz | Default 8 kHz; low‑noise option available |
| DC Bus Capacitance | Integrated | For voltage stabilization |
| Loss Power | ~0.12 kW | At full load |
Physical & Environmental Parameters
| Parameter | Value | Notes |
|---|---|---|
| Dimensions (W×H×D) | 50 × 360 × 260 mm | Compact Plus design |
| Weight | 3.8 kg (8.4 lbs) | Lightweight for panel mounting |
| Protection Class | IP20 | Indoor, panel‑mounted |
| Cooling | Forced air | ~0.003 m³/s airflow |
| Acoustic Noise | ≤ 22 dB(A) | At 50 Hz, low‑noise design |
| Operating Temperature | 0–40 °C | Derate above 30 °C |
| Storage Temperature | -25–+70 °C | |
| Humidity | 5–80% RH | Non‑condensing |
| Max Altitude | 1000 m | Derate above 1000 m |
| Vibration | IEC 60068‑2‑6 | 1g, 10–200 Hz |
| Shock | IEC 60068‑2‑27 | 15g, 11 ms |
Performance & Control Features
| Feature | Specification | |
|---|---|---|
| Speed Regulation Accuracy | ±0.01% (closed‑loop with encoder) | ±0.5% (sensorless vector) |
| Torque Response | < 10 ms | High dynamic for motion control |
| Overload Capacity | 150% for 60 s, 300% for 3 s | Standard overload |
| Positioning Accuracy | ±1 pulse (with high‑res encoder) | For indexing/positioning tasks |
| Control Interfaces | Analog: 2×AI, 2×AO; Digital: 6×DI, 3×DO | Isolated, configurable |
| Encoder Support | TTL, HTL, Sin/Cos, Resolver | Closed‑loop feedback |
| Communication | PROFIBUS DP (standard), PROFINET (option), DeviceNet, USS, SIMOLINK | Industrial network connectivity |
| Protection Functions | Overcurrent, overvoltage, undervoltage, overtemperature, earth fault, motor overload, short circuit | Comprehensive protection |
Electrical Connections
| Connection | Specification | |
|---|---|---|
| DC Input Terminals | 3×16 mm² (E‑CU) | For DC bus connection |
| Motor Output Terminals | 3×6 mm² | U, V, W to motor |
| Control Terminals | Screw terminals | 0.5–2.5 mm² |
| Auxiliary Power | 24 V DC ±10% | For control logic |
General Specifications
| Item | Details | |
|---|---|---|
| Product Status | Discontinued (Sep 30, 2020) | |
| Certifications | CE, UL, cUL, C‑Tick | Industrial safety standards |
| Control Unit | CUVC (Compact Universal Control) | Standard on MC series |
| Software Version | V2.xx | Latest firmware for motion control |
| Mounting | Vertical panel mount | DIN rail or direct screw fix |
| RoHS Compliance | Non‑compliant |
