| Main |
| Range of Product |
Modicon Quantum automation platform |
| Product or Component Type |
Analogue output module |
| Complementary |
| Analogue output number |
4 |
| Addressing requirement |
4 output words |
| Analogue output range |
+/- 10 V >= 1000 Ohm bipolar voltage |
| +/- 5 V >= 500 Ohm bipolar voltage |
| 0…10 V >= 1000 Ohm unipolar voltage |
| 0…5 V >= 500 Ohm unipolar voltage |
| Analogue output resolution |
12 bits |
| Analogue output current |
-10…10 mA |
| Source resistance |
0.1 Ohm |
| Maximum cable distance between devices |
1312.3 ft (400 m) |
| Absolute accuracy error |
+/- 0.15 % of full scale 77 °F (25 °C) |
| Linearity |
+/- 1 LSB |
| Accuracy drift according to temperature |
0.003 % of full scale/°C unipolar |
| 0.004 % of full scale/°C bipolar |
| 0.005 % of full scale/°C maximum unipolar |
| 0.007 % of full scale/°C maximum bipolar |
| Isolation between channels |
500 V for 1 minute 47…63 Hz AC |
| Isolation between channels and bus |
780 V for 1 minute AC |
| Update time |
3 ms |
| Setting time |
700 µs to +/- 0.1 % of the final value maximum |
| Bus current requirement |
700 mA |
| Maximum power dissipation in W |
4.5 W |
| Associated fuse rating |
0.063 mA 3 AG fast blow 250 V |
| Marking |
CE |
| Local signalling |
1 LED (green) for bus communication is present (Active) |
| 1 LED (red) for external fault |
| 4 LEDs (green) for channel is turned on |
| 4 LEDs (red) for channel fault |
| Module format |
Standard |
| Net Weight |
0.7 lb(US) (0.3 kg) |
| Environment |
| Resistance to electromagnetic fields |
9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3 |
| Ambient Air Temperature for Operation |
32…140 °F (0…60 °C) |
| Ambient Air Temperature for Storage |
-40…185 °F (-40…85 °C) |
| Relative Humidity |
95 % without condensation |
| Operating altitude |
<= 16404.2 ft (5000 m) |
