BMXEHC0200
counter module, Modicon M340, high speed, 2 channels
| Main | |
| Range of Product | Modicon M340 automation platform |
| Product or Component Type | Counter module |
| Number of Channels | 2 |
| Maximum counting frequency | 60000 Hz |
| Number of inputs | 6 |
| Input compatibility | 19.2…30 V 2-wire/3-wire proximity sensor |
| incremental encoder with push-pull outputs, 10…30 V totem pole | |
| Input voltage | 24 V DC type 3 |
| Number of outputs | 2 |
| Output voltage | 24 V DC |
| Complementary | |
| Cycle time | 1 ms |
| Isolation voltage | 1500 V 60 s |
| Input type | 3 auxiliary input |
| 3 high speed | |
| Nominal input voltage | 30 V |
| Nominal input current | 2 mA at 11 V |
| Voltage state 1 guaranteed | 11…30 V |
| Current state 1 guaranteed | >= 6 mA |
| Voltage state 0 guaranteed | < 5 V |
| Current state 0 guaranteed | <= 1.5 mA |
| Discrete output logic | Positive or negative configurable |
| Maximum output current | 2 A per module |
| 0.5 A per output | |
| Output voltage limits | 19.2…30 V |
| Maximum load current | 1 A per module |
| 0.5 A per output | |
| Maximum leakage current | 0.1 mA at state 0 |
| Maximum voltage drop | <3 V at state 1 |
| Output overload protection | Integrated |
| Output short-circuit protection | 1.5 A integrated |
| Overlap time | 0.2 ms |
| Module format | Standard |
| Net Weight | 0.247 lb(US) (0.112 kg) |
| Environment | |
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
| Relative Humidity | 10…95 % without condensation |
| IP Degree of Protection | IP20 |
| Directives | 2014/35/EU – low voltage directive |
| 2014/30/EU – electromagnetic compatibility | |
| Protective treatment | TC |
| Ordering and shipping details | |
| Category | US1PC3418160 |
| Discount Schedule | PC34 |
| GTIN | 3595863910148 |
| Returnability | Yes |
| Country of origin | FR |
