| Main |
| Range of Product |
Harmony XBTGT |
| Product or Component Type |
Advanced touchscreen panel |
| Display Type |
Backlit colour STN LCD |
| Display colour |
4096 colours |
| Display Resolution |
640 x 480 pixels VGA |
| Display size |
7.5 inch |
| Software Type |
Configuration software |
| Software Designation |
Vijeo Designer |
| Operating System |
Harmony |
| Processor name |
CPU RISC |
| Processor frequency |
266 MHz |
| Memory description |
512 KB SRAM back up of data lithium battery |
| 32 MB flash EPROM application memory |
| Integrated connection type |
RJ45 COM2 serial link RS485 <= 187.5 kbit/s Siemens MPI (187.5 kbits/s) |
| male SUB-D 9 COM1 serial link RS232C/RS422/RS485 <= 115.2 kbits/s |
| removable screw terminal block power supply |
| RJ45 Ethernet TCP/IP |
| 3 removable screw terminal block digital output |
| removable screw terminal block audio output |
| removable screw terminal block digital input |
| USB type A master port (V1.1) |
| Resistance to electrostatic discharge |
6 kV IEC 61000-4-2 level 3 |
| Cut-out dimensions |
204.5 (+ 1/- 0) x 159.5 (+ 1/- 0) mm |
| Complementary |
| Touch sensitive zone |
1024 x 1024 |
| Touch panel |
Analogue |
| Backlight lifespan |
54000 hours |
| Brightness |
8 levels via touch panel |
| Contrast |
8 levels via touch panel |
| Character font |
Chinese (simplified Chinese) |
| ASCII (European characters) |
| Korean |
| Taiwanese (traditional Chinese) |
| Japanese (ANK, Kanji) |
| [Us] rated supply voltage |
24 V DC |
| Supply |
External source |
| Supply voltage limits |
19.2…28.8 V |
| Inrush current |
30 A |
| Power Consumption in W |
28 W |
| Local signalling |
1 LED (green or orange) for normal operation or backlighting faulty |
| Number of pages |
Limited by internal memory capacity |
| Downloadable protocols |
Telemecanique Modicon FIPWAY |
| Telemecanique Modicon Modbus Plus |
| Telemecanique Modicon Modbus TCP |
| Telemecanique Modicon Modbus |
| Mitsubishi Melsec third party protocols |
| Omron Sysmac third party protocols |
| Rockwell Automation Allen-Bradley third party protocols |
| Siemens Simatic third party protocols |
| Telemecanique Modicon Uni-TE |
| Realtime clock |
Built-in |
| Data storage equipment |
1 Compact Flash card >= 1 GB |
| Use of slot |
For 1 fieldbus communication card (Device Net, Profibus DP) |
| Port Ethernet |
10BASE-T/100BASE-TX |
| Product mounting |
Flush mounting |
| Fixing Mode |
By 4 screw clamps |
| By 4 spring clips |
| Front material |
Aluminium alloy |
| Enclosure Material |
PPT |
| Marking |
CE |
| Width |
8.5 in (215 mm) |
| Height |
6.7 in (170 mm) |
| Depth |
2.4 in (60 mm) |
| Product Weight |
4.0 lb(US) (1.8 kg) |
| Environment |
| Immunity to microbreaks |
10 ms |
| Standards |
EN 61131-2 |
| UL 508 |
| FCC Class A |
| CSA C22.2 No 14 |
| UL 1604 |
| IEC 61000-6-2 |
| Product Certifications |
C-tick |
| ATEX zone 2/22 |
| cULus |
| CSA Class 1 Division 2 T4A |
| UL Class 1 Division 2 T5 |
| UL Class 1 Division 2 T4A |
| CSA Class 1 Division 2 T5 |
| Ambient air temperature for operation |
32…122 °F (0…50 °C) |
| Ambient Air Temperature for Storage |
-4…140 °F (-20…60 °C) |
| Relative humidity |
10…90 % without condensation |
| Operating altitude |
< 6561.68 ft (2000 m) |
| IP degree of protection |
IP20 IEC 60529 rear panel) |
| IP65 IEC 60529 front panel) |
| NEMA degree of protection |
NEMA 4X front panel (indoor use) |
| Shock resistance |
15 gn 11 ms IEC 60068-2-27 |
| Vibration resistance |
1 gn 9…150 Hz)IEC 60068-2-6 |
| 3.5 mm 5…9 Hz)IEC 60068-2-6 |
| Resistance to electromagnetic fields |
9.1 V/m (10 V/m) IEC 61000-4-3 |
| Resistance to fast transients |
2 kV IEC 61000-4-4 level 3 |
| Ordering and shipping details |
| Category |
US10MC222569 |
| Discount Schedule |
0MC2 |
| GTIN |
3595863885712 |
| Returnability |
No |
| Country of origin |
US |
