peripheral remote IO adaptor module, Modicon X80, max 1024 discrete with 256 analog IO, Ethernet
BMXPRA0100
| Main | |
| Range of Product | Modicon X80 |
| Product or Component Type | Peripheral remote I/O adaptor |
| Complementary | |
| Number of port | 1 |
| Integrated connection type | Ethernet/IP device network |
| Communication Port Protocol | Modbus TCP |
| Realtime clock | With |
| Memory capacity | 448 kB internal |
| 96 kB removable | |
| Application structure | 1 master task |
| Local signalling | 1 LED (green) for module active (RUN) |
| 1 LED (red) for module error (ERR) | |
| 1 LED (red) for external fault (I/O) | |
| 1 LED (green) for activity on Ethernet network (ETH ACT) | |
| 1 LED (red) for memory card fault (CARD ERR) | |
| 1 LED (green) for Ethernet link diagnostics (STS) | |
| 1 LED (green) for Ethernet network status (link) | |
| Product compatibility | 0…1024 discrete I/O module |
| 0…256 analog I/O module | |
| 0…2 Ethernet module | |
| Average consumption in mA | 95 mA |
| Power dissipation in W | 2.3 W |
| Marking | CE |
| Module format | Standard |
| Maximum altitude transport | 9842.5 ft (3000 m) |
| Relative Humidity | 95 % without condensation |
| Environment | |
| Environmental characteristic | Hazardous location class I division 2 |
| IP Degree of Protection | IP20 |
| Ambient Air Temperature for Operation | -13…158 °F (-25…70 °C) |
| Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Operating altitude | <= 6561.68 ft (2000 m) |
| Ordering and shipping details | |
| Category | US1PC3418160 |
| Discount Schedule | PC34 |
| GTIN | 3595864063317 |
| Returnability | Yes |
| Country of origin | FR |
