| Main |
| Range of Product |
Modicon Quantum automation platform |
| Product or Component Type |
Relay discrete output module |
| Discrete output number |
8 |
| Complementary |
| Contacts type and composition |
1 NO/NC |
| Contact form |
Form C |
| Discrete output voltage |
20…250 V AC |
| 30…150 V DC |
| 5…30 V DC |
| Addressing requirement |
0.5 output word |
| Maximum load current |
100 mA 30…50 V DC L/R = 10 ms |
| 2 A 250/30 V AC/DC tungsten 1/4 hp cos phi = 0.4 |
| 3 A 250/30 V AC/DC |
| 300 mA 30…50 V DC resistive |
| 5 A 250/30 V AC/DC resistive 140 °F (60 °C) |
| Surge current |
20 A 10 ms capacitive |
| Switching frequency |
30 Hz resistive |
| F = 0.5/I²L inductive |
| Switching capacity in VA |
1250 VA resistive |
| Maximum response time on input open |
10 ms at state 0 to state 1 |
| 20 ms at state 1 to state 0 |
| Mechanical durability |
10000000 cycles |
| Electrical durability |
100000 cycles 100 mA 30…150 V DC L/R = 10 ms |
| 100000 cycles 30…150 V DC interposing relay |
| 100000 cycles 300 mA 30…150 V DC resistive |
| 100000 cycles 5 A 30 V DC resistive |
| 200000 cycles 5 A 250 V AC resistive |
| 50000 cycles 500 mA 30…150 V DC resistive |
| Output overvoltage protection |
Internal by varistor, 275 V |
| Isolation between channels |
1780 Vrms AC for 1 minute |
| 2500 V DC |
| Isolation between channels and bus |
1780 Vrms AC for 1 minute |
| 2500 V DC for 1 minute |
| Power dissipation |
2.75 W + (0.5 x the number of points on) |
| Marking |
CE |
| Local signalling |
1 LED (green) for bus communication is present (Active) |
| 1 LED (red) for external fault detected (F) |
| 8 LEDs (green) for input status |
| Bus current requirement |
560 mA |
| Module format |
Standard |
| Net Weight |
0.7 lb(US) (0.3 kg) |
| Environment |
| Standards |
UL 508 |
| CSA C22.2 No 142 |
| Resistance to electrostatic discharge |
4 kV contact IEC 801-2 |
| 8 kV on air IEC 801-2 |
| Resistance to electromagnetic fields |
9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3 |
| Ambient Air Temperature for Operation |
32…140 °F (0…60 °C) |
| Ambient Air Temperature for Storage |
-40…185 °F (-40…85 °C) |
| Relative Humidity |
95 % without condensation |
| Operating altitude |
<= 16404.2 ft (5000 m) |
