| Part number |
ATV930C16N4C |
| Range of Product |
Altivar Process ATV900 |
| Product Specific Application |
Process for industrial |
| Product or Component Type |
Variable speed drive |
| Variant |
Without braking chopper |
| Standard version |
| Device Application |
Industrial Application |
| Product destination |
Synchronous motors |
| Asynchronous motors |
| Phase |
3 phase |
| Mounting Mode |
Wall mount |
| Continuous output current |
302 A 2.5 kHz normal duty |
| 250 A 2.5 kHz heavy duty |
| Communication Port Protocol |
Modbus serial |
| Modbus TCP |
| EtherNet/IP |
| [Us] rated supply voltage |
380…480 V – 15…10 % |
| [Us] rated supply voltage |
380…480 V |
| Relative symmetric mains voltage tolerance |
10% |
| Relative symmetric network frequency tolerance |
5% |
| nominal output current |
302.0 A |
| Motor power kW |
160.0 kW normal duty |
| 132.0 kW heavy duty |
| EMC filter |
Integrated |
| With EMC plate option |
| IP degree of protection |
IP21 |
| Degree of protection |
UL type 1 |
| Minimum switching current |
Relay output R1, R2, R3 5 mA 24 V DC |
| Discrete input logic |
16 preset speeds |
| Physical interface |
Ethernet |
| 2-wire RS 485 |
| Connector Type |
2 RJ45 |
| 1 RJ45 |
| Method of access |
Slave Modbus TCP |
| Transmission Rate |
10, 100 Mbits |
| 4.8 kbps |
| 9600 bit/s |
| 19200 bit/s |
| Transmission frame |
RTU |
| Number of addresses |
1…247 |
| Data format |
8 bits, configurable odd, even or no parity |
| Type of polarization |
No impedance |
| 4 quadrant operation possible |
FALSE |
| Asynchronous motor control profile |
Variable torque standard |
| Constant torque standard |
| Optimized torque mode |
| Synchronous motor control profile |
Permanent magnet motor |
| Synchronous reluctance motor |
| Maximum output frequency |
599 Hz |
| Acceleration and deceleration ramps |
Linear adjustable separately from 0.01…9999 s |
| Motor slip compensation |
Automatic whatever the load |
| Can be suppressed |
| Adjustable |
| Not available in permanent magnet motor law |
| Switching frequency |
1…8 kHz adjustable |
| 2.5…8 kHz with derating factor |
| Nominal switching frequency |
2.5 kHz |
| Braking to standstill |
By DC injection |
| Brake chopper integrated |
FALSE |
| Line current |
284.0 A 380 V normal duty) |
| 237.0 A 380 V heavy duty) |
| 262.0 A 480 V normal duty) |
| 213.0 A 480 V heavy duty) |
| Maximum Input Current per Phase |
284.0 A |
| Maximum output voltage |
480.0 V |
| Apparent power |
201.3 kVA 480 V normal duty) |
| 161.4 kVA 480 V heavy duty) |
| Maximum transient current |
362 A 60 s normal duty) |
| 375 A 60 s heavy duty) |
| Network Frequency |
50-60 Hz |
| Prospective line Isc |
50 kA |
| Base load current at high overload |
250.0 A |
| Base load current at low overload |
302.0 A |
| Quantity per Set |
1 |
| Width |
12.6 in (320 mm) |
| Height |
33.5 in (852 mm) |
| Depth |
15.5 in (393 mm) |
| Product Weight |
180.8 lb(US) (82 kg) |
