6SE7090-0XX85-1DA0 USR FOR SIMOVERT MD Control Unit Extension Board (CUVC)
| Parameter | Specification | Remarks |
|---|---|---|
| Part Number | 6SE7090-0XX85-1DA0 | Siemens SIMOVERT MASTERDRIVES VC |
| Product Type | Control Unit Extension Board (CUR) | Vector control for 6SE70/6SE71 MD series |
| Power Supply | 24 V DC (internal) | Backplane bus powered |
| Communication | USS, PROFIBUS‑DP (optional), CANopen | Depends on sub‑configuration |
| Digital Inputs | 6 (programmable) | High‑speed counter capable |
| Digital Outputs | 3 (relay/transistor) | Check manual for max load |
| Analog Inputs | 2 (12‑bit) | Voltage/current selectable |
| Operating Temperature | 0 °C to +55 °C | Ambient, non‑condensing |
| Storage Temperature | −20 °C to +60 °C | Dry environment |
| Relative Humidity | ≤95 % (non‑condensing) | No corrosive gases |
| Altitude | ≤2000 m | Derate above 1000 m |
| Protection Class | IP20 | For internal mounting |
| Weight | 0.4 kg (0.88 lb) | Approximate |
| Dimensions (L×W×H) | 165 × 375 × 45 mm | Approximate |
| Control Modes | V/f, Vector Control (VC) | Closed‑loop/encoder optional |
| Application | Infeed, regenerative feedback, motion control | For 6SE70 series AC drives |
