6ES7414-3XM07-0AB0 (SIMATIC S7-400 CPU 414-3) English Technical Specifications
The 6ES7414-3XM07-0AB0 is a SIMATIC S7-400 CPU 414-3 with a 4 MB work memory (2 MB code, 2 MB data), 2 PROFIBUS DP interfaces plus 1 MPI/DP interface, drawing a typical 1.1 A from the backplane 5 V DC, max 450 mA from 24 V DC, and having a typical power loss of 5.5 W. Below is the detailed English specification table:
| Parameter | Value |
|---|---|
| Order Number | 6ES7414-3XM07-0AB0 |
| Product Type | SIMATIC S7-400 CPU 414-3 |
| Firmware Version | V7.0 |
| Work Memory | 4 MB (2 MB code, 2 MB data) |
| Interfaces | 1. MPI/DP (12 Mbit/s); 2. PROFIBUS DP; 3. Plug – in IFM module interface |
| Power Supply | Supplied via system voltage (no independent 24 V DC rating) |
| Current from Backplane Bus (5 V DC) | Typical: 1.1 A; Maximum: 1.3 A |
| Current from Backplane Bus (24 V DC) | Maximum: 450 mA (150 mA per DP interface) |
| Current from 5 V DC Interface | Maximum: 90 mA (per DP interface) |
| Power Loss | Typical: 5.5 W; Maximum: 6.5 W |
| Backup Current | Typical: 180 μA; Maximum: 850 μA |
| HW Functional Status | 01 |
| Cir Synchronization Time | Basic load: 100 ms; Per I/O byte: 15 μs |
| Required Engineering System | STEP 7 V5.4 or higher (with HSP 261) |
