6ES7660-5HF28-3FK6
SIMATIC PCS 7 Industrial Workstation IPC647D; (Rack PC, 19″, 2HE), Interfaces: 2x Gbit LAN (RJ45), 1x DVI-I, 2x Display Port; 1x COM, 2x PS/2, Audio; 2x USB 3.0; 2x USB 2.0 on rear, 1x USB 3.0; 1x USB 2.0, on front; 1x USB 3.0 internal; Temperature and fan monitoring Watchdog; card retainer; Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB cache, TB, VT-D, AMT); OS Server; RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring); in removable frame, hot swap; on front; 16 GB DDR3 SDRAM (2x 8 GB), Dual Channel; Without additional system bus communication cards; PCS 7 V9.0 SP2 pre-installed Windows Server 2016 Standard Edition Incl. 16 cores, 5 clients 64 bit, MUI (en/de/fr/it/sp/ch); bus module 4 slots: 1x PCIE X16 (8 lane), 3x PCIE X16 (4 lane); DVD +/-RW (slim); 2 x 100/240V redund. power supply unit; without power supply cable
| Product | |
| Article Number (Market Facing Number) | 6ES7660-5HF28-3FK6 |
| Product Description | SIMATIC PCS 7 Industrial Workstation IPC647D; (Rack PC, 19″, 2HE), Interfaces: 2x Gbit LAN (RJ45), 1x DVI-I, 2x Display Port; 1x COM, 2x PS/2, Audio; 2x USB 3.0; 2x USB 2.0 on rear, 1x USB 3.0; 1x USB 2.0, on front; 1x USB 3.0 internal; Temperature and fan monitoring Watchdog; card retainer; Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB cache, TB, VT-D, AMT); OS Server; RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring); in removable frame, hot swap; on front; 16 GB DDR3 SDRAM (2x 8 GB), Dual Channel; Without additional system bus communication cards; PCS 7 V9.0 SP2 pre-installed Windows Server 2016 Standard Edition Incl. 16 cores, 5 clients 64 bit, MUI (en/de/fr/it/sp/ch); bus module 4 slots: 1x PCIE X16 (8 lane), 3x PCIE X16 (4 lane); DVD +/-RW (slim); 2 x 100/240V redund. power supply unit; without power supply cable |
| Series name | SIMATIC PCS 7 |
| Industrial Workstation IPC647D | |
| Rack PC | |
| Size | 19″ |
| Processor type/CPU | Xeon E3-1268LV3 |
| Memory capacity | 16 GB DDR3 SDRAM |
| Harddisk | 2x 1 TB HDD SATA |
| Operating system/OS | Windows Server 2016 Standard Edition Incl. 16 cores, 5 clients 64 bit, MUI |
| Other interface | 2x Gbit LAN (RJ45), 1x DVI-I, 2x Display Port; 1x COM, 2x PS/2, Audio; 2x USB 3.0; 2x USB 2.0 on rear, 1x USB 3.0; 1x USB 2.0, on front; 1x USB 3.0 internal |
| Power supply | 2 x 100/240V |
| Warranty | 1 year |
| Net Weight (kg) | 15.000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 84715000 |
| LKZ_FDB/ CatalogID | STPCS7 |
| Product Group | 2321 |
| Group Code | R336 |
