Basic Identification
表格
| Item | Specification |
|---|---|
| Order Number | 6SE7038-2EH35-1AA0 |
| Product Series | SIMOVERT MASTERDRIVES MC |
| Type | Regenerative Feedback Unit / Rectifier Unit |
| Voltage Class | 690 V class |
| Frame Size | H |
| Protection | IP00 (open chassis) |
| Cooling | Forced air cooling |
Electrical Input Data (Mains Side)
表格
| Parameter | Value |
|---|---|
| Input Voltage | 3 AC 660…690 V |
| Frequency | 50 / 60 Hz |
| Rated Input Current | 837 A |
| Rated Apparent Power | 1000 kVA |
DC Link Output Data
表格
| Parameter | Value |
|---|---|
| Nominal DC Link Voltage | 930 V DC |
| DC Voltage Range | 875 V … 930 V DC |
| Rated DC Current | 837 A |
| Rated Active Power | 400 kW |
| Overload | 110% for 60 s every 10 min
150% for 3 s |
Control & Auxiliary
表格
| Parameter | Value |
|---|---|
| Control Supply Voltage | 24 V DC ±10% |
| Auxiliary Power Consumption | ≤ 150 W |
| Power Factor | ≥ 0.95 at rated load |
| Efficiency | ≥ 98 % |
Environmental & Mechanical
表格
| Parameter | Value |
|---|---|
| Ambient Temperature | 0 … +40 °C (derate above) |
| Storage Temperature | -25 … +70 °C |
| Humidity | 5% … 95% non-condensing |
| Dimensions (W×H×D) | approx. 600 × 1200 × 565 mm |
| Weight | approx. 350 kg |
