6SL3220-1YE56-0CB0
SINAMICS G120X Rated power: 315 kW at 135% 3 sec or 110% 60 sec, 100% 240 sec; RFI suppression filter For category C3 3AC380-480V+10/-20% 47-63Hz Ambient temperature 0 to +45 °C Size: FSH Degree of protection IP20 / UL open type Without operator panel Without IO expansion Integrated fieldbus: MODBUS RTU, BACnet MS/TP,USS
| Product | |
| Article Number (Market Facing Number) | 6SL3220-1YE56-0CB0 |
| Product Description | SINAMICS G120X Rated power: 315 kW at 135% 3 sec or 110% 60 sec, 100% 240 sec; RFI suppression filter For category C3 3AC380-480V+10/-20% 47-63Hz Ambient temperature 0 to +45 °C Size: FSH Degree of protection IP20 / UL open type Without operator panel Without IO expansion Integrated fieldbus: MODBUS RTU, BACnet MS/TP,USS |
| Series name | SINAMICS G120X |
| Rated power | |
| Power Rated | 315 kW |
| Power voltage | 3AC380-480V+10/-20% |
| Frequency（HZ）频率 | 47-63Hz |
| Integrated Fieldbus | MODBUS RTU, BACnet MS/TP,USS |
| Protection Level | IP20 |
| Warranty | 1 YEAR |
| Net Weight (kg) | 151.000 Kg |
| Packaging Dimension | 1870.00 x 800.00 x 600.00 |
| Country of origin | China |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | 4042948689127 |
| UPC | 804766938870 |
| Commodity Code | 85044086 |
| LKZ_FDB/ CatalogID | D31.5 |
| Product Group | 4R53 |
| Group Code | R220 |
