| Basic Identification |
Full MLFB Order Number |
6AV7241-5KG34-0FA0 |
|
Product Designation |
SIMATIC IPC 477E |
|
Manufacturer |
Siemens AG, Germany |
|
Lifecycle Status |
Phase-out / Discontinued production |
| Display & Multi-Touch Module |
Screen Diagonal |
19-inch industrial TFT LCD |
|
Native Resolution |
WXGA 1366 × 768 pixels |
|
Touch Technology |
Capacitive multi-touch (5-point touch, glove operable) |
|
Front Panel Protection Rating |
IP65 (dustproof, splash-resistant) |
|
Rear Chassis Protection |
IP20 (cabinet flush mounting only) |
|
Standard Luminance |
300 cd/m² industrial brightness |
|
Backlight MTBF @25°C Ambient |
60,000 hours |
| Core Hardware Platform |
CPU (Code K) |
Intel Core i5-6442EQ, 4C/4T, Base 2.0 GHz / Turbo 2.7 GHz, 6 MB L3 Cache, TDP=15W |
|
Chipset |
Intel Q170 embedded chipset |
|
Integrated Graphics |
Intel HD 530 Graphics, dual independent display output |
|
System RAM (Code G34) |
8 GB DDR4 industrial SO-DIMM with onboard NVRAM; max expandable to 16 GB |
|
Cooling Architecture |
Fully sealed fanless passive aluminum heat dissipation, zero maintenance |
| Storage Configuration (Suffix F) |
Main Internal Storage |
240 GB industrial SATA SSD (fixed onboard, non-replaceable front access) |
|
Expandable Storage Bay |
No hot-swap replaceable storage slot |
|
Optical Drive |
Not equipped; external USB optical drive optional |
| Onboard Communication Interfaces |
Industrial Ethernet |
3 × Gigabit RJ45 (10/100/1000 Mbps), PROFINET / Industrial Ethernet compliant |
|
Serial COM Ports |
2 × configurable RS232 / RS485 serial interfaces |
|
USB Interfaces |
1 × front service USB 2.0; 4 × rear USB 3.0 Type-A |
|
External Video Output |
2 × DisplayPort for multi-monitor expansion |
|
PCIe Expansion Slot |
No PCIe expansion slot equipped |
| Operating System (Suffix 0) |
Factory Pre-installed OS |
Windows 7 Ultimate SP1 64-bit Multi-Language MUI (EN / DE / FR / IT / ES) |
| Visualization Runtime (Suffix A0) |
SIMATIC Runtime Software |
No WinCC RT Advanced / Professional runtime pre-installed |
| Power Supply Specifications |
Nominal Input Voltage |
24 V DC industrial power supply |
|
Allowed Voltage Tolerance |
19.2 V DC ~ 28.8 V DC (-20% / +20%) |
|
Max Full-Load Power Consumption |
49 W |
| Mechanical Dimensions |
Front Panel W × H |
462 mm × 302 mm |
|
Cabinet Cutout Size (W × H) |
443 mm × 283 mm |
|
Overall Installation Depth |
85 mm |
|
Approximate Net Weight |
6.9 kg |
| Environmental Ratings |
Continuous Operating Temp (Vertical Cabinet Mount) |
0 °C ~ +45 °C (performance derating above +40°C) |
|
Storage & Transportation Temperature |
-20 °C ~ +60 °C |
|
Relative Humidity |
5% ~ 90% RH, non-condensing |
|
Max Operation Altitude |
≤ 3,000 m above sea level |
|
Vibration Compliance Standard |
IEC 60068-2-6: 5–500 Hz, 1 g operational |
|
Shock Compliance Standard |
IEC 60068-2-27: 15 g, 11 ms operational |
| Certifications & Compliance |
Global Approvals |
CE, cULus, UL508, FCC Class A, RCM, KC, EAC; DNV / ABS marine certification optional |
