| Parameter | Specification |
|---|---|
| Model Number | 6DL1134‑6TH00‑0PH1 |
| Product Type | Analog Input Module AI 16 x I 2‑wire mA HART |
| Series | SIMATIC ET 200SP HA |
| Number of Channels | 16 channels, 2‑wire transmitter connection |
| Measuring Range | 4 … 20 mA |
| Resolution | 16‑bit (including sign bit) |
| Basic Accuracy | ±0.1 % of full‑scale range |
| HART Protocol | Support HART V5 ~ V7, act as HART master, max 8 mapped HART variables |
| Channel Diagnostics | Yes; wire‑break, short‑circuit, overload, supply monitoring |
| Redundancy Support | Yes, with M1‑type terminal block |
| Terminal Block Compatible | H1, M1, N0, H0, M1 |
| Color Code | CC01 |
| Supply Voltage | 19.2 V DC ~ 28.8 V DC |
| Module Power Consumption | 90 mA typical |
| CiR (Configuration in RUN) | Parameter re‑assignable in RUN mode |
| I&M Data | I&M0 to I&M3 supported |
| Firmware | V1.1, field upgradable |
| Engineering Tool | TIA Portal ≥V16, STEP7 V5.6, PCS7 ≥V9.0, PCS neo ≥V3.0 |
| Communication Profile | PROFINET, GSDML V2.3 |
| Dimensions (W×H×D) | 35 mm ×150 mm ×130 mm |
| Weight | 0.3 kg |
| Operating Temperature | ‑40 °C ~ +70 °C |
| Protection Class | IP20 (module body) |
| Country of Origin | Germany |
