6AV7242-3CC10-1AA0
| Order Number | 6AV7242-3CC10-1AA0 |
| Product Designation | SIMATIC IPC PX-39A |
| Display | 22″ multi-touch, 1920 × 1080 (Full HD) |
| Integrated Graphics | Intel UHD Graphics (onboard) |
| Onboard I/O (USB) | 4 × USB 3.2 ports |
| Onboard I/O (Ethernet) | Ethernet (10/100/1000 Mbps) |
| Expansion Slot | PCIe (optional) |
| Processor (CPU) | Intel Xeon W-11155MLE (1.8 / 3.1 GHz, 4 cores / 8 threads) |
| Memory (RAM) | 16 GB |
| Primary Storage | M.2 SSD, 256 GB (Eco variant) |
| Secondary Storage | None (without 2nd mass storage) |
| Operating System | Windows 10 IoT Enterprise 2021 LTSC (for Celeron, Xeon W-11155MLE, Xeon W-11555MLE) |
| Additional Options | None (without option 1) |
| Recovery / Software Image | Restore stick image with D&D and software image (if selected) available exclusively via OSD (online portal) |
| Power Supply | 24 V DC industrial power supply |
| warranty | 1 YEAR |
| Net Weight (kg) | 8,200 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
