6AG4131-2GH30-0BX6
SIMATIC IPC627D (Box PC), HD graphic onboard, 2x Gigabit Ethernet (IE/PN) 4xUSB V3.0; 1x serial (COM 1); RAID controller onboard; Watchdog, temp./fan monitoring XEON E3-1268LV3 (4C/8T, 2.3 (3.3) GHz, 8 MB cache VT-D, AMT) RAID1 2x 320 GB SATA (2.5″); DVD +/-RW 8 GB DDR3 1600 DIMM; 2x PCI without expansion (HW) Windows 7 Ultimate 64 bit SP1, MUI (de, en, fr, es, it) without expansion (software) 24 V DC industrial Power supply
| Order Number | 6AG4131-2GH30-0BX6 |
| Product Family | SIMATIC IPC627D (Box PC) |
| Product Type | Industrial Box PC |
| Graphics | HD graphics onboard (integrated) |
| Ethernet Interfaces | 2 × Gigabit Ethernet (IE/PN – Industrial Ethernet / PROFINET) |
| USB Interfaces | 4 × USB V3.0 |
| Serial Interface | 1 × serial port (COM 1) |
| Storage Controller | RAID controller onboard |
| System Monitoring | Watchdog timer / temperature and fan monitoring |
| Processor | Intel Xeon E3-1268LV3 (4 cores / 8 threads, 2.3 GHz base / 3.3 GHz turbo, 8 MB cache, supports VT-d and AMT) |
| Storage Configuration | RAID1: 2 × 320 GB SATA HDD (2.5″ form factor) |
| Optical Drive | DVD ± RW |
| System Memory (RAM) | 8 GB DDR3 1600 DIMM |
| Expansion Slots | 2 × PCI slots (free / available) |
| Hardware Expansions | Without additional hardware expansions (base configuration only) |
| Operating System | Windows 7 Ultimate 64-bit SP1, MUI |
| Pre‑installed Software | Without additional software expansions (base configuration only) |
| Power Supply | 24 V DC industrial power supply |
| Net Weight | 6.000 kg |
| Packaging Dimensions | Not available |
| Country of Origin | Germany |
