6AV7260-4DM30-0BX6
| Order Number | 6AV7260-4DM30-0BX6 |
| Product Family | SIMATIC IPC677D (Panel PC) |
| Product Type | Industrial Panel PC |
| Ethernet Interfaces | 2 × 10/100/1000 Mbit/s Ethernet |
| USB Interfaces | 4 × USB V3.0 |
| Serial Interface | 1 × serial (COM1) |
| System Monitoring | Watchdog timer, temperature and fan monitoring |
| Storage Controller | RAID controller onboard |
| Display | 19″ Multitouch (1366 × 768) |
| Processor | Intel Core i3‑4330TE (2 cores / 4 threads, 2.4 GHz, 4 MB cache, VT‑x) |
| Mass Storage | Solid‑state drive (SSD) 240 GB |
| System Memory (RAM) | 8 GB DDR3 1600 DIMM |
| Expansion Slots | 2 × PCI slots (free / available) |
| Hardware Expansions | Without additional hardware expansions (base configuration) |
| Operating System | Windows 7 Ultimate 64‑bit SP1 MUI |
| Pre‑installed Software | No additional expansion software included (base configuration only) |
| Power Supply | 24 V DC industrial power supply |
| Net Weight | 17.00 kg |
| Packaging Dimensions (L × W × H) | Not available |
| Country of Origin | Germany |
