Basic Information
0005-4050-818 is a customized operator panel assembly for GEA, compatible with Siemens SIMATIC HMI OP177B DP (blue mode) operator panel. It is a complete assembly including touch screen, membrane keypad, plastic case cover and LCD display, mainly used for GEA centrifuge and other industrial equipment control[1][2][3]. Its electrical parameters are consistent with the Siemens OP177B series, and the physical and functional parameters are customized for GEA equipment[1][7].
Power Supply Specifications
|
Parameter Item
|
Detailed Specification
|
|
Rated Supply Voltage
|
24V DC[1]
|
|
Maximum Current Consumption
|
0.55A DC (Consistent with OP177B standard)
|
|
Rated Power Consumption
|
13.2W (Calculated by P=U×I, 24V×0.55A)[4]
|
|
Allowable Supply Voltage Range
|
20.4V DC ~ 28.8V DC (Reference to Siemens HMI standard range)
|
|
Reverse Polarity Protection
|
Yes (Consistent with OP177B standard)
|
Digital Output Specifications
|
Parameter Item
|
Detailed Specification
|
|
Number of Digital Outputs
|
16 (Consistent with OP177B standard)
|
|
Rated Output Voltage
|
24V DC
|
|
Maximum Output Current per Channel
|
0.5A (Reference to Siemens OP177B standard)
|
|
Short-circuit Protection
|
Yes
|
Display Specifications
|
Parameter Item
|
Detailed Specification
|
|
Screen Diagonal
|
5.7 inches[1]
|
|
Display Type
|
STN LCD[1]
|
|
Active Display Area
|
115.18mm × 86.38mm (Consistent with OP177B standard)
|
|
Resolution
|
320 × 240 pixels[1]
|
|
Displayable Colors
|
4 blue levels (Adapted to OP177B DP blue mode)[1]
|
|
Backlighting Half Brightness Life (Typical)
|
50,000 hours (CCFL, Consistent with OP177B standard)
|
|
Contrast Control
|
Yes
|
Input Unit Specifications
|
Parameter Item
|
Detailed Specification
|
|
Input Unit Type
|
Resistive analog touch screen + membrane keypad[3][7]
|
|
Touch Screen Active Area
|
117mm × 88mm[5]
|
|
Character Size
|
5mm (Consistent with OP177B standard)
|
Communication Interface Specifications
|
Parameter Item
|
Detailed Specification
|
|
Communication Protocols
|
MPI / Profibus-DP (Consistent with OP177B standard)
|
|
Interface Types
|
RS422 / RS485 / USB (Consistent with OP177B standard)
|
|
Additional Interface
|
Printer interface; Slot for MM-card (Consistent with OP177B standard)
|
Mechanical & Other Specifications
|
Parameter Item
|
Detailed Specification
|
|
Exterior Dimensions
|
138mm × 109mm (Touch screen exterior)[5]; Overall dimensions: 180mm × 180mm × 150mm[1]
|
|
Weight
|
0.70 kg[1]
|
|
Memory Capacity
|
2048 kbyte[1]
|
|
Programming Software Requirement
|
WinCC Flexible 2005 or higher (Consistent with OP177B standard)
|
|
Warranty Period
|
12 months (Standard warranty for new products)[3][5]; 1 month RMA policy for some suppliers[7]
|
|
Country of Manufacture
|
Germany (Original); China (Replacement parts)[1][3][5]
|
|
Commodity Code
|
85371098[1]
|
