| Parameter Category | Detailed Specifications |
|---|---|
| Basic Information | |
| Product Model | 6ES7647‑6AF20‑0HK0 |
| Product Family | SIMATIC Box PC 627 |
| Form Factor | Compact industrial box PC, metal enclosure |
| Dimensions (W×D×H) | 297 × 267 × 100 mm |
| Weight | Approx. 7.05 kg |
| Protection Class | IP20 (front) |
| Processor | |
| CPU | Intel Pentium M 760, 2.0 GHz |
| FSB | 533 MHz |
| Cache | 2 MB L2 cache |
| Memory | |
| RAM Type | DDR2 SDRAM |
| Standard RAM | 1 GB (expandable up to 2 GB) |
| Memory Slots | 1 SODIMM slot |
| Storage | |
| Hard Disk | 80 GB SATA 2.5‑inch HDD |
| Storage Expansion | 1 CompactFlash slot (front‑mounted) |
| RAID | Onboard RAID controller (RAID 0/1) |
| Graphics | |
| Controller | Onboard AGP graphics |
| Video Memory | 8–128 MB shared system memory |
| Max Resolution | 1600 × 1200 @ 85 Hz, 32‑bit color |
| Display Output | Analog VGA |
| Interfaces | |
| Ethernet | 2 × 10/100 Mbit/s RJ45 (dual LAN) |
| USB | 4 × USB 2.0 (high‑current) |
| Serial | 1 × RS‑232 (COM1) |
| Expansion Slots | 2 × PCI slots (175/265 mm) with card retainer |
| Power Supply (AC Input) | |
| Nominal Voltage | 100–240 V AC (auto‑ranging) |
| Voltage Range | 85–264 V AC |
| Frequency | 50/60 Hz (47–63 Hz) |
| Continuous Current | ≤ 2.3 A |
| Inrush Current | ≤ 50 A (peak for 1 ms at startup) |
| Power Supply (DC Input) | |
| Nominal Voltage | 24 V DC (SELV) |
| Voltage Range | 19.2–28.8 V DC |
| Continuous Current | ≤ 8 A |
| Inrush Current | ≤ 14 A (peak for 30 ms at startup) |
| Power & Efficiency | |
| Max Power Consumption | 190 W (active) / 210 W (peak) |
| Voltage Ride‑Through | ≥ 20 ms (NAMUR compliant) |
| Internal Rail Voltages | +5 V / 16.5 A; +3.3 V / 8.5 A; +12 V / 6.5 A (8 A peak); −12 V / 0.3 A |
| Total Internal Power | Max 150 W |
| Environmental | |
| Operating Temperature | 0–40 °C (standard) |
| Storage Temperature | −20–60 °C |
| Humidity | 10–90% RH (non‑condensing) |
| Shock Resistance | 15 g, 11 ms (half‑sine) |
| Vibration Resistance | 1 g (5–500 Hz) |
| Noise Level | < 55 dB(A) |
| Software & OS | |
| Preinstalled OS | Windows XP Professional (Multi‑Language) |
| Supported OS | Windows 2000 Professional, Windows XP Professional |
| Reliability Features | |
| Watchdog | Hardware watchdog timer |
| Monitoring | Temperature & fan speed monitoring |
| Power Fail Handling | NAMUR‑compliant voltage ride‑through |
| EMC | EN 55022 Class B, EN 61000‑6‑2/‑6‑4 |
