6AV7240-3BC07-0NA8 (SIMATIC IPC 477D) English Technical Specifications
The 6AV7240-3BC07-0NA8 is a SIMATIC IPC 477D 15″ touch industrial panel PC, powered by 24 V DC (19.2-28.8 V range), with 5 A max input current, 120 W typical power, Core i3-3217UE CPU, 4 GB DDR3 RAM, 320 GB HDD, 2×Gigabit Ethernet, 4×USB 3.0, fanless design, and Windows 7 Ultimate 64-bit. Below is the detailed English specification table covering electrical and key technical parameters:
| Parameter | Value |
|---|---|
| Order Number | 6AV7240-3BC07-0NA8 |
| Product Type | SIMATIC IPC 477D 15″ Touch Industrial Panel PC |
| Power Supply | 24 V DC (permissible range: 19.2–28.8 V DC) |
| Max Input Current | 5 A (24 V DC) |
| Typical Power Consumption | 120 W |
| Inrush Current | 30 A (peak, 24 V DC, 10 ms) |
| Display | 15″ widescreen TFT; Resolution 1280×800 pixels; Resistive single – touch; 16.7 million colors; Backlight MTBF 50,000 h (25 °C) |
| Processor | Intel Core i3-3217UE (2C/4T, 1.6 GHz, 3 MB L3 cache) |
| Memory | 4 GB DDR3 SDRAM; 320 GB HDD; Windows 7 Ultimate 64-bit |
| Interfaces | 1. 2× Gigabit Ethernet (IE/PN, 10/100/1000 Mbps); 2. 4× USB 3.0 (back); 3. 1× USB 2.0 (front); 4. 1× RS – 232 (COM); 5. 1× DVI – I; 6. 1× DisplayPort |
| Cooling System | Fanless (passive cooling) |
| Protection Rating | Front: IP65; Housing: IP20 |
| Operating Temperature | 0-50 °C (non – condensing) |
| Dimensions (W×H×D) | 415 mm×310 mm×76 mm (front width×height×installation depth) |
| Weight | Approx. 6.4 kg |
| Certifications | CE, UL, RoHS compliant |
| Successor Model | SIMATIC IPC 477E (6AV7241 series) |
