6AV7240-3BD04-0RD0 (SIMATIC IPC477D 15″) English Technical Specifications
The 6AV7240-3BD04-0RD0 is a SIMATIC IPC477D 15″ industrial panel PC, with 24 V DC (19.2-28.8 V) power, 2.5 A rated input current, 60 W typical power, Intel Celeron U827E CPU, 4 GB DDR3L RAM, 80 GB SSD, fanless design, 2×Gigabit Ethernet, 4×USB, 1×COM, and Windows Embedded Standard 7 SP1 32-bit. Below is the detailed English specification table covering electrical and key technical parameters:
| Parameter | Value |
|---|---|
| Order Number | 6AV7240-3BD04-0RD0 |
| Product Type | SIMATIC IPC477D 15″ Industrial Panel PC (15″ Touch Display, Celeron U827E, Win Embedded Standard 7 SP1 32-bit) |
| Power Supply | 24 V DC (permissible range: 19.2–28.8 V DC, -20% / +20%) |
| Rated Input Current | 2.5 A (24 V DC, typical); Max 3.5 A (peak inrush) |
| Inrush Current | 25 A (peak, 24 V DC, 10 ms) |
| Active Power Consumption | Typical: 60 W (without expansion); Max: 65 W (with full load) |
| Voltage Failure Buffering | 10 ms (24 V DC cut-off) |
| Display | 15″ widescreen TFT, LED backlight; Resolution 1280×800 pixels; Resistive single – touch; 16.7 million colors; LED backlight MTBF 50,000 h (25 °C) |
| Processor | Intel Celeron U827E (1C/1T, 1.4 GHz, 1.5 MB L2 cache) |
| Graphics | Intel HD Graphics (integrated, max resolution 1920×1200 via DP) |
| Memory | 4 GB DDR3L RAM (max 8 GB); 80 GB SSD (MLC, replaceable) |
| Interfaces | 1. 2× Gigabit Ethernet (10/100/1000 Mbps, IE/PN); 2. 4× USB 2.0 (back panel); 3. 1× RS – 232 (COM); 4. 1× DisplayPort, 1× DVI – I; 5. PROFIBUS DP12 (optional) |
| Cooling System | Fanless (passive cooling) |
| Protection Rating | Front: IP65; Housing: IP20 |
| Operating Temperature | 0-45 °C (non – condensing) |
| Storage Temperature | -20-60 °C |
| Dimensions (W×H×D) | 482 mm×303 mm×75 mm (front width×height×installation depth) |
| Weight | Approx. 6.2 kg |
| Certifications | CE, UL, RoHS compliant |
| Lifecycle Status | Discontinued (since 01.09.2021); Successor: 6AV7241 – … (SIMATIC IPC 477E) |
