| MLFB Order Code |
6AV7251-1DB05-0DA0 |
| Full Product Name |
SIMATIC IPC477D PRO fully enclosed IP65 industrial Panel PC |
| Product Series Generation |
IPC477D PRO (Predecessor model; successor: IPC477E PRO) |
| Display Spec |
15″ widescreen TFT LED backlight, 1366 × 768 HD resolution |
| Touch Screen Type |
Projective capacitive multi-touch |
| Mounting Form |
Round pipe support arm mounting (expandable bracket) |
| Processor Unit |
Intel Celeron G3902E (2 Core / 2 Thread, 1.6 GHz, 2 MB L3 Cache) |
| Motherboard Chipset |
Intel H110 |
| Integrated Graphics |
Intel HD Graphics onboard |
| Main Memory (RAM) |
8 GB DDR4-2400 SO-DIMM, max expandable to 16 GB |
| Mass Storage Device |
256 GB Eco SATA SSD, non-replaceable storage module |
| Pre-installed OS |
Windows 10 IoT Enterprise 2016 LTSB 64-bit Multi-language UI (MUI) |
| Front Panel Interfaces |
No front USB ports |
| Rear-side Interfaces |
4 × USB 3.0; 3 × Gigabit RJ45 Ethernet (IE / PROFINET); 1 × DisplayPort; 1 × HDMI; 24 V DC power terminal block |
| Serial Communication Ports |
Without RS232 / RS422 / RS485 serial COM ports |
| PCIe Expansion Slot |
No PCIe expansion slot available |
| Industrial Power Input |
Rated 24 V DC, 20 ms voltage drop/mains failure buffer |
| Front Enclosure Protection Class |
IP65 (Dust-proof, splash-proof front panel) |
| EMC & Safety Certifications |
CE, EN 61000-6-4, CISPR 22 Class A, FCC Class A |
| Marine Ship Certifications |
GL, ABS, DNV, LRS, KRS marine approval |
| Horizontal Installation Operating Temp |
0 °C ~ +60 °C (non-condensing environment) |
| Vertical Installation Operating Temp |
0 °C ~ +50 °C (non-condensing environment) |
| Max Operational Altitude |
Up to 5,000 meters above sea level |
| Continuous Operation Capability |
24/7 non-stop industrial operation support |
| Bundled SIMATIC Runtime Software |
No pre-installed WinCC / SIMATIC software |
| Product Lifecycle Status |
PM410 (Discontinued since Sep 01, 2021; available only as spare part) |
| Export Control Classification |
ECCN: 5A992, AL: N |
| Single Unit Net Weight |
Approx. 8.0 kg |
| Packaging Quantity |
1 unit per export package |
| Standard Ex-Work Lead Time |
30 working days |
| Ambient Humidity (Operation) |
5% to 85% RH at 30 °C, no condensation |
| Vibration Resistance Standard |
IEC 60068-2-6: 10–58 Hz: 0.075 mm; 58–200 Hz: 9.8 m/s² (1g) |
