| Parameter Item | Official Specification |
|---|---|
| Part Number | 6AV7886-0CB11-2AB0 |
| Full Model Name | SIMATIC IPC277G Nanopanel Industrial Panel PC |
| Display | 12-inch widescreen multi-touch TFT LCD, native resolution 1280 × 800 |
| Processor | Intel Atom X6413E 4-core industrial low-power CPU |
| System Memory | 4 GB DDR4 RAM |
| Mass Storage | 256 GB Eco industrial SSD, shock-resistant, no mechanical moving parts |
| Power Supply | DC 24 V industrial wide voltage input |
| Graphic Interfaces | 2 × DisplayPort video outputs for multi-monitor expansion |
| Network Interfaces | 3 × Gigabit RJ45 Ethernet (PROFINET/Industrial Ethernet RT capable) |
| USB Interfaces | 4 × USB 3.1 high-speed ports |
| Expansion Slots | 2 × internal M.2 slots for communication or storage extension |
| Serial Port | Equipped with 1 × COM1 RS232 serial interface |
| Preinstalled OS | Windows 10 IoT Enterprise 2019 LTSC 64-bit MUI; languages: en, de, fr, it, es |
| Hardware Monitoring | Built-in watchdog timer, temperature and backlight monitoring |
| Protection Class | Front panel IP65 dustproof and splashproof, cabinet rear IP20 |
| Mounting Mode | Cabinet flush embedded mounting |
| Net Weight | 4.0 kg |
| Product Lifecycle | Active production model, available as new original and spare parts |
| Country of Origin | Germany |
