6AV8106-3BB00-0FH0
| Category | Official Technical Parameter |
|---|---|
| Market Article Number | 6AV8106-3BB00-0FH0 |
| Official Model Designation | SCD 1997-RTF Industrial LCD Touch Monitor |
| Product Family | SIMATIC PANEL Industrial Display Series |
| Screen Size | 19-inch color TFT LCD industrial panel |
| Native Resolution | 1280 × 1024 SXGA |
| Touch Interface | Analog resistive touch, compatible with gloves/stylus |
| Front Panel Feature | Custom customer branded front plate with dedicated mounting dowel pins |
| Front Protection Grade | IP65 dust-proof & splash-proof for cabinet front |
| Built-in Interfaces | Dual PS/2 ports for industrial keyboard & mouse connection |
| Video Input | Standard VGA analog video input with DSP image scaling |
| Backlight Type | Long-life CCFL backlight, industrial 24/7 continuous operation |
| Power Supply | 24 V DC industrial control power (19.2–28.8V DC tolerance) |
| Installation Method | Cabinet flush embedded mounting |
| Mechanical Reference | Same installation cutout dimension as SCD1897-RTF (6GF6223-6MB) |
| Operating Temperature | 0°C ~ +50°C horizontal cabinet installation |
| Enclosure Material | Robust aluminum industrial front frame |
| Certification | Industrial EMC, global machinery safety compliance |
| Special Custom Code Suffix -0FH0 | Custom front fascia with customer logo, fixed dowel pin layout |
