6ES7647-8BB22-0CA1
SIMATIC IPC227E (Nanobox PC); 1x display port; 2x 10/100/1000 Mbit/s Ethernet RJ45; 1 x USB3.0, 3 x USB2.0; CFast slot; 24 V DC industrial power supply Celeron N2930 (4C/4T) 4 GB RAM; Box: Basis with COM 1/2 without operating system 240 GB SSD; without SIMATIC software DIN rail mounting
| Parameter Item | Specification |
|---|---|
| Article Number | 6ES7647-8BB22-0CA1 |
| Product Model | SIMATIC IPC227E Nanobox Industrial PC |
| Processor | Intel Celeron N2930, 4 Cores / 4 Threads, SoC integrated chipset |
| Main Memory | 4 GB DDR3L SO-DIMM, max expandable to 8 GB |
| Local Storage | 240 GB Industrial SATA SSD |
| Operating System | Without pre-installed operating system |
| Visual Interface | 1 × DisplayPort |
| Industrial Ethernet | 2 × RJ45 Gigabit Ethernet (10/100/1000 Mbit/s) |
| USB Interfaces | 1 × USB3.0, 3 × USB2.0 |
| Serial Port | 2 × COM ports (COM1/COM2, RS232/422/485 switchable via BIOS) |
| Expansion Slot | 1 × CFast memory card slot |
| Power Supply | 24 V DC industrial power input, 20ms voltage drop buffer |
| Housing Version | Basis box with dual COM serial ports |
| Mounting Method | Standard DIN rail mounting support |
| Cooling Design | Fanless passive cooling, maintenance-free |
| Monitoring Functions | Onboard temperature monitoring, hardware watchdog, status LED indicators |
| Software Configuration | Delivered without preloaded SIMATIC automation software |
| Protection Grade | IP40 cabinet interior use |
| Operating Temperature | 0 ℃ ~ +60 ℃ |
| Product Lifecycle | Phase-out since 31.07.2025 (PM400) |
| Origin | Germany, Siemens official industrial IPC series |
