6ES7660-5HJ11-0DA5
SIMATIC PCS 7 Industrial Workstation IPC647D; (Rack PC, 19″, 2HE), Interfaces: 2x Gbit LAN (RJ45), 1x DVI-I, 2x Display Port; 1x COM, 2x PS/2, Audio; 2x USB 3.0; 2x USB 2.0 on rear, 1x USB 3.0; 1x USB 2.0, on front; 1x USB 3.0 internal; Temperature and fan monitoring Watchdog; card retainer; Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB cache, TB, VT-D, AMT); OS Server; RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring); in removable frame, hot swap; on front; + 240 GB SSD (EMLC) SATA, internal in ODD slot; 8 GB DDR3 SDRAM (2 x 4 GB), Dual Channel; Industrial Ethernet (CP1623); PCS 7 V8.0 SP2 pre-installed; Windows Server 2008 R2 Standard edition incl. 5 clients, 64 bit, MUI (en/de/fr/it/es/cn); bus module 4 slots: 2x PCI, 2x PCIE X16 (8 lane), without optical drive; 100/240V industrial power supply unit; with NAMUR; power supply cable China
| Product | |
| Article Number (Market Facing Number) | 6ES7660-5HJ11-0DA5 |
| Product Description | SIMATIC PCS 7 Industrial Workstation IPC647D; (Rack PC, 19″, 2HE), Interfaces: 2x Gbit LAN (RJ45), 1x DVI-I, 2x Display Port; 1x COM, 2x PS/2, Audio; 2x USB 3.0; 2x USB 2.0 on rear, 1x USB 3.0; 1x USB 2.0, on front; 1x USB 3.0 internal; Temperature and fan monitoring Watchdog; card retainer; Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB cache, TB, VT-D, AMT); OS Server; RAID1, 1 TB (2x 1 TB HDD SATA, data mirroring); in removable frame, hot swap; on front; + 240 GB SSD (EMLC) SATA, internal in ODD slot; 8 GB DDR3 SDRAM (2 x 4 GB), Dual Channel; Industrial Ethernet (CP1623); PCS 7 V8.0 SP2 pre-installed; Windows Server 2008 R2 Standard edition incl. 5 clients, 64 bit, MUI (en/de/fr/it/es/cn); bus module 4 slots: 2x PCI, 2x PCIE X16 (8 lane), without optical drive; 100/240V industrial power supply unit; with NAMUR; power supply cable China |
| Series name | SIMATIC PCS 7 |
| Industrial Workstation | |
| IPC647D | |
| Rack PC | |
| Screen size | 19″ |
| Processor type/CPU | Xeon E3-1268LV3 |
| Memory capacity | 8 GB DDR3 SDRAM |
| Harddisk | 1 TB |
| Dual channel | |
| Operating system/OS | Windows Server 2008 |
| Network Interface | 2x Gbit LAN (RJ45) |
| Other interface | 1x DVI-I, 2x Display Port; 1x COM, 2x PS/2, Audio; 2x USB 3.0; 2x USB 2.0 on rear, 1x USB 3.0; 1x USB 2.0, on front; 1x USB 3.0 |
| Power supply | 100/240V |
| Programming software | without |
| Warranty | 1 YEAR |
| Net Weight (kg) | 15,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 84715000 |
| LKZ_FDB/ CatalogID | STPCS7 |
| Product Group | 2321 |
| Group Code | R336 |
